SQUARENESS TESTERS Schut for Precision
TESA Micro-Square 350/600
The TESA Micro-Square is a robust perpendicularity measuring instrument to measure the
squareness of your squares and workpieces quickly and with high precision. The holder can be set
to the correct height by hand, after which the deviation can be read by means of a lever-type dial test
indicator. The lever-type dial test indicator can be placed on the Micro-Square by means of a fixing
shaft with dovetail joint. With the GT31 analog probe and the TWIN-T10 display, it is possible to
read the measured values digitally. The data can also be sent to a PC by means of the (wireless) TESA
Link Connector and the free TESA DATA VIEWER PC software.
Measuring range: Micro-Square 350: 360 mm,
Micro-Square 600: 610 mm.
Repeatability: 0.5 µm.
Perpendicularity front:
Micro-Square 350: ± 1.5 µm,
Micro-Square 600: ± 2.4 µm.
Weight: Micro-Square 350: 5.8 kg,
Micro-Square 600: 7.7 kg.
Delivery with a SCS calibration certificate.
Delivery with a manual.
TESA Micro-Square set
Standard supplied items:
– TESA dial test indicator GT31 (780.652),
– TESA TWIN-T10 (783.468),
– hex key 1.5 mm.
783.640 + 783.652 783.653 783.654
Item No. Description Price EUR
783.654 TESA Micro-Square 350
783.655 TESA Micro-Square 600 C07.316.EN.20250106
783.640 TESA Micro-Square 350 set
783.641 TESA Micro-Square 600 set
Options:
783.652 Base for positioning and clamping of squares
783.653 Cylindrical probes for GT31 for use on e.g. beveled edge squares
780.172 Fixing shaft ø 8 x 12 mm
