Schut Geometrical Metrology                                   INTERNAL MEASURING INSTRUMENTS

Marposs M1 Star internal bore gauges

  The Marposs bore gauges are ideal for checking bores with high accuracy. The measurements can
be performed quickly and extremely repetitively by everyone, even in the workshop. The measuring
heads are supplied based on the minimum value to be measured. The transfer of measurements to, for
example, Microsoft Excel is possible via an optional digital dial indicator. Both wireless and wired.

	 Measuring range: 3 - 300 mm.                               	 Excl. dial indicator or measuring probe.
	 Read-out depends on the type of dial indicator             	 Special-purpose gauge heads and extensions

  or measuring probe.                                           available on request.
	 Accuracy (L = measuring range): 	                          	 Also available with stylus tip for RA ≥ 2 µm.
                                                              	 Several accessories available.
    0 -   26 mm: ± (3%L + 1 µm), 	                            	 Robust holders with an integrated display
  26 - 300 mm: ± (1%L + 1 µm).
	 Repeatability: ≤ 0.001 mm.                                   and Bluetooth transmitter can also be ordered
	 Clamping shaft: ø 8 mm.                                      on request. These can be used stand-alone
	 Tungsten carbide stylus tip.                                 or together with other holders. An external
	 Available for blind bores and through bores.                 graphic display with product drawing is also
                                                                possible.

Standard measuring heads

Diameter 	   Thread 	 C	             Measuring	 Price
   mm                     	mm	       range/mm	 EUR

	 3	 -	 4 	 M3.5 	  2.5	                0.055	 418.00                      C                             C = 1 mm
                                        0.055	 366.00
	 4	 -	 4.5 	 M3.5 	  2.5	              0.070	 366.00         Standard               Blind bores                           Through bore
                                        0.120	 366.00
	 4.5	-	 5.5 	 M3.5 	  2.5	             0.120	 331.00
                                        0.120	 331.00
	 5.5	-	 7.5 	 M3.5 	 3	                0.120	 331.00 C
                                        0.120	 384.00
	 7.5	-	 9.5 	 M3.5 	 3	                0.150S	tanda4r3d1.00
                                        0.150	 470.00
	 9.5	-	 15 	 M6    	 3	                0.150	 513.00
                                        0.150	 544.00
	 15	 -	 20 	 M6    	 3	                0.150	 570.00                      C = 1 mm                                                  C = 6 or 8 mm
                                        0.150	 6C0=31.0m0m                                               Through bores
	 20	 -	 26 	 M6    	  3.5	         Blind0.b1o5r0e	s 629.00

	 26	 -	 40 	 M10 	  3.5	                                     Blind bores

	 40	 -	 50 	 M10 	  3.5

	 50	 -	 60 	 M10 	  3.5

	 60	 -	 70 	 M10 	  3.5	                                                                                Basic instrument
                                                                                                         compact model
	 70	 -	 80  	 M10  	  3.5	                                                               C = 6 or 8 mm
	 80	 -	 90  	 M10  C	  3.5
                                                              Through bores
	 90	 -	100 S	 tandMar1d0 	  3.5
                                                                Price EUR
Larger sizes available on request.                                   195.00
                                                                     183.00
Item No.     Description                                             206.00                                                                         C04.341.EN.20250321
                                                                      96.00
880.000      M1 Star handle with M3.5 thread                          82.00
880.001      M1 Star handle with M6 thread                           106.00
880.002      M1 Star handle with M10 thread
                                                                      49.00
880.003      M1 Star handle with M3.5 thread compact                  49.00
880.004      M1 Star handle with M6 thread compact                    14.50
880.005      M1 Star handle with M10 thread compact                   18.10
                                                                      22.00
Options:     Dial indicator protector depth 39 mm
880.007      Dial indicator protector depth 52 mm
880.006      Adapter M3.5 for M6 handle
880.008      Adapter M3.5 for M10 handle
880.009      Adapter M6 for M10 handle
880.010

© 2025, Schut Geometrische Meettechniek bv            171     Measuring instruments and systems 2025/2026
