Schut Geometrical Metrology INTERNAL MEASURING INSTRUMENTS

Krœplin digital internal measuring instruments (3-point)

Krœplin digital internal measuring instruments (3-point) for easier centering. 854.716
 Measuring range: 7 - 105 mm.
 Resolution: 0.001, 0.002, 0.005, 0.01, 0.02 or

0.05 mm, adjustable.
 mm/inch conversion.
 ABS/INC switchable.
 Mitutoyo Digimatic, Mitutoyo U-WAVE,

Bluetooth and USB data outputs optionally
available.
 Automatic switch-off.
 Storage for 100 measuring values.
 Reset/preset.
 With tolerance display by means of red/green LED.
 Hold and min/max functions.
 Protection: IP67.
 Delivery with a manufacturer measuring report.
 Power supply: 2 batteries AAA.

Item No. Type Meas. Groove Groove Type Insert Types of inserts
depth depth width of length
L/mm A/mm B/mm Hb/mm
insert
34 2.2 0.8
854.715 L107P3 75 3.5 1.6  2.5 ➀
854.716 L210P3 77 5.0 1.6  4.6
854.717 L215P3 84 7.0 1.6  5.8 TC-ball
854.718 L225P3 84 8.0 1.6  7.3 ø 0.6 mm
854.719 L240P3 84 8.0 1.6  12.2
854.720 L255P3 84 8.5 1.6  12.2
854.721 L270P3 84 9.0 1.6  12.2
854.722 L285P3  12.2

Item No. Measuring Accuracy Repeatability Price
range/mm mm mm EUR

854.715 7 - 14 ± 0.01 0.004 530.60
0.01 530.60
854.716 10 - 20 ± 0.02 0.01 530.60
0.01 530.60
854.717 15 - 30 ± 0.02 0.01 530.60
0.01 530.60
854.718 25 - 45 ± 0.02 0.01 530.60
0.01 530.60
854.719 40 - 60 ± 0.02 ➁
0.80
854.720 55 - 75 ± 0.02 47.10
72.00
854.721 70 - 90 ± 0.02 124.00 TC-ball
98.00 ø 1 mm
854.722 85 - 105 ± 0.02 109.20
9.60
Options: Spare battery type AAA 53.40 ➂
497.914 Interface type 1961-09 31.90
854.952 1 Digimatic cable TC-ball C04.317.EN.20240625
965.013 1 USB cable ø 1 mm
206.380 1 U-WAVE cable
102.790 1 Bluetooth interface adapter type 1961-13 (only K and L series)
854.092 2 Bluetooth PC dongle type 0682-60
854.073 Wooden case type 1732-65 (only K and L series)
854.113 Wooden case type 1732-45 (only C and G series)
859.233

1 For data output an interface and cable are needed.
2 Bluetooth interface adapter is delivered with a Bluetooth PC dongle (854.073).

© 2024, Schut Geometrische Meettechniek bv 167 Measuring instruments and systems 2023/2024
