INTERNAL MEASURING INSTRUMENTS Schut for Precision
Mitutoyo bore gauges with dial indicator
Internal measuring instruments used for measuring diameters of cylindrical bores and form
deviations for instance roundness and cylindricity, compared to standards such as setting rings. In
order to read out the measured values, any existing dial indicator or measuring probe with a clamping
stem of ø 8 mm can be used. The reversal point marks the diameter of the bores. When using digital
indicators a model with a hold function for minimal measuring value is recommended. Please see the
dial indicators section for these dial indicators.
Measuring range: 18 - 400 mm. Several accessories available.
Measuring range dial indicator: Delivery in a plastic case with dail indicator
204.601: 0 - 10 mm,
210.912: 0 - 1 mm, and measuring inserts.
543.310: 0 - 12.7 mm. Other models also available, including for the
Read-out depends on the type of dial indicator
measurement of blind bores.
or measuring probe.
Accuracy: 0.002 mm.
Repeatability: 0.0005 mm.
Clamping shaft: ø 8 mm.
Interchangeable measuring inserts with
tungsten carbide stylus tip.
Plastic cover for dial indicator.
B
Item No. Measuring Dial indicator Read-out Measuring Price EUR
range/mm No. mm depth (B)/mm
511.711 18 - 35 204.601 0.01 100 305.00 511.711
511.712 35 - 60 204.601 0.01 150 311.00
511.713 50 - 150 204.601 0.01 150 324.00
511.714 100 - 160 204.601 0.01 150 510.00
511.715 160 - 250 204.601 0.01 250 631.00
511.716 250 - 400 204.601 0.01 250 751.00
511.721 18 - 35 210.912 0.001 100 370.00
511.722 35 - 60 210.912 0.001 150 377.00
511.723 50 - 150 210.912 0.001 150 389.00
511.724 100 - 160 210.912 0.001 150 586.00
511.725 160 - 250 210.912 0.001 250 707.00
511.726 250 - 400 210.912 0.001 250 833.00
Sets
Item No. Measuring Dial indicator Read-out Price EUR
range/mm No. mm
Analog: 597.00
511.921 18 - 150 204.601 0.01 648.00
511.922 18 - 150 210.912 0.001
Digital (with determination of the reversal point): 511.921 C04.315.EN.20250106
511.925 18 - 150 543.310 0.001 1,040.00
