INTERNAL MEASURING INSTRUMENTS Schut for Precision

Schwenk internal measuring instruments with ball probes

Special internal measuring instruments for Item No. Diameter Thread Price
measuring profiles and internal gearing without mm EUR
a centering bridge. The fixed pin gauge and
interchangeable inserts come with internal Set of ball probes (pair) 1 for 852.625: 176.00
screw thread, in which ball probes can be 176.00
placed. 852.107 1 M1.6 176.00
 Measuring range: 8 - 510 mm.
 Read-out depends on the type of dial indicator 852.004 1.5 M1.6 167.00
167.00
or measuring probe. 852.005 2 M1.6 167.00
 Accuracy: ≤ 0.002 mm. 167.00
 Repeatability: ≤ 0.0005 mm. Set of ball probes (pair) 1 for 852.627: 167.00
 Clamping shaft: ø 8 mm. 167.00
 Ball probes available from ø 0.5 mm, 852.982 1 M1.6 167.00

incrementing with 0.001 mm. 852.006 1.5 M1.6 167.00
Deviation diameter: < 0.002 mm. 167.00
 Delivery in a wooden case with measuring 852.007 2 M1.6 167.00
inserts and spacer rings (from 12 mm). 167.00
 Excl. ball probes and dial indicator or 852.008 2.5 M1.6 167.00
measuring probe. 167.00
852.009 3 M1.6 167.00
167.00
852.675 3.5 M1.6 167.00
167.00
852.671 4 M1.6 167.00
167.00
Set of ball probes (pair) 1 for 852.629: 167.00
223.00
852.092 1 M2.5 223.00
223.00
852.010 1.5 M2.5 223.00
223.00
852.011 2 M2.5 223.00

852.012 2.5 M2.5 167.00
167.00
852.674 3 M2.5 167.00
167.00
852.650 3.5 M2.5 167.00
167.00
852.676 4 M2.5 167.00
167.00
852.651 4.5 M2.5 167.00
167.00
852.677 5 M2.5 167.00
167.00
852.013 5.5 M2.5 167.00
223.00
852.655 6 M2.5 223.00
223.00
852.014 6.5 M2.5 223.00
223.00
852.678 7 M2.5 223.00

852.015 7.5 M2.5

852.016 8 M2.5

852.017 8.5 M2.5

852.018 9 M2.5

852.019 9.5 M2.5

852.020 10 M2.5

Set of ball probes (pair) 1 for 852.632 / 852.636:

852.021 1 M4

852.022 1.5 M4

Internal measuring instruments 852.023 2 M4

852.116 2.5 M4

Item No. Measuring Measuring Price 852.670 3 M4

range/mm depth/mm EUR 852.653 3.5 M4

852.913 4 M4

852.625 8 - 12 100 938.00 852.186 4.5 M4
852.627 12 - 22 102 892.00
852.629 22 - 55 110 665.00 852.672 5 M4
852.632 55 - 250 177 728.00
852.636 100 - 510 235 860.00 852.195 5.5 M4

852.673 6 M4

852.024 6.5 M4

852.914 7 M4

852.635 Adapter for ball probes 35.20 852.025 7.5 M4
(M1.6 / M2.5) 35.20
852.026 8 M4
852.091 Adapter for ball probes
(M2.5 / M4) 852.027 8.5 M4

852.657 9 M4

852.028 9.5 M4

852.656 10 M4

See for dial indicators the page “Schwenk precision dial 1 Special sizes on request. C04.223.EN.20250702
indicators”.
See for measuring probes the pages “Measuring probes”.
