P. 156
INTERNAL MICROMETERS Schut for Precision
TESA Imicro digital capa µ three-point internal micrometers
These TESA Imicro internal micrometers combine the unique measuring cone, that prevents
spindle errors, with the patented capa µ measuring system.
Measuring range: ø 3.5 - 300 mm. Sets delivered in a plastic carrying case with a
Resolution: 0.001 mm. manufacturer measuring report.
mm/inch conversion.
ABS/INC switchable. Power supply: 1 battery type CR2032.
Opto-RS232C data output, bidirectional. Electronic measuring elements, several sets,
Automatic switch-off.
Reset/preset. individual measuring heads and extensions
Measuring faces: available.
ø 3.5 - 12 mm: hardened steel,
ø 11 - 100 mm: titanium nitride (TiN),
ø 100 - 300 mm: tungsten carbide.
Protection: IP54.
(When using data output: IP40.)
DIN 863 T4.
Delivery in a plastic case (ø 3.5 - 40 mm) or a
wooden case with a manufacturer measuring
report.
782.562
782.543
Sets with individual measuring heads Complete sets
Consist of 1 electronic measuring element with Consist of all the instruments of the measur
interchangeable measuring heads, setting rings ing range, setting rings and an extension (no
and an extension (no extension for the 782.564). extension for the 782.558).
Item No. Measuring range/mm Price EUR Item No. Measuring range/mm Price EUR
782.564 ø 3.5 - 6.5 5,263.00 782.558 ø 3.5 - 6.5 6,562.00
782.565 ø 6 - 12 2,692.00 782.559 ø 6 - 12 3,985.00
782.566 ø 11 - 20 2,890.00 782.560 ø 11 - 20 4,125.00
782.567 ø 20 - 40 3,780.00 782.561 ø 20 - 40 5,612.00
782.568 ø 40 - 100 6,966.00 782.562 ø 40 - 100 10,175.00
782.569 ø 100 - 200 9,663.00 782.563 ø 100 - 200 12,509.00
Extensions Option
Item No. Extension For measuring Price Item No. Description Price EUR
mm range/mm EUR
495.157 Spare battery type CR2032 0.50
779.609 100 ø 6 - 12 101.00
779.623 150 ø 11 - 20 213.00 Accessories for (wireless) data transfer C04.206.EN.20240625
779.625 150 ø 20 - 40 153.00 available on request.
779.628 150 ø 40 - 100 174.00
779.631 150 ø 100 - 200 213.00
© 2024, Schut Geometrische Meettechniek bv 156 Measuring instruments and systems 2023/2024
