INTERNAL MICROMETERS Schut for Precision

Mitutoyo Borematic digital three-point internal micrometers

Three-point internal micrometers with the absolute measuring system and a large 6‑digit LCD
display for an easy read-out of the measurement and tolerance indication. The tolerance values are
shown graphically above the current measurement or full size on the display. The 330° rotatable display
guarantees an ideal read-out in any position. Easy and fast one-handed operation.

 Measuring range: ø 6 - 125 mm.  Reset/preset.
 Resolution: 0.001 mm.  Hold function.
 Accuracy: refer to the table. Only valid with  Adjustable tolerance limits.
 Measuring faces of hardened steel, with
close contact of all measuring surfaces.
 ABS/INC switchable. titanium nitride (TiN) coating.
 LCD display 330° rotatable.  Conforms to factory standard.
 Digimatic data output.  Delivery in a wooden case with a
 On/off switch.
manufacturer measuring report.
 Power supply: 1 battery type V357.

Item No. Measuring range/mm Accuracy/mm Price EUR
1,405.00
568.361 ø 6 - 8 ± 0.005 1,405.00
568.362 ø 8 - 10 ± 0.005 1,405.00
568.363 ø 10 - 12 ± 0.005 1,434.00
568.364 ø 12 - 16 ± 0.005 1,434.00
568.365 ø 16 - 20 ± 0.005 1,528.00
568.366 ø 20 - 25 ± 0.006 1,528.00
568.367 ø 25 - 30 ± 0.006 1,659.00
568.368 ø 30 - 40 ± 0.006 1,659.00
568.369 ø 40 - 50 ± 0.006 1,733.00
568.370 ø 50 - 63 ± 0.006 1,768.00
568.371 ø 62 - 75 ± 0.006 1,825.00
568.372 ø 75 - 88 ± 0.006 1,825.00
568.373 ø 87 - 100 ± 0.006 1,933.00
568.374 ø 100 - 113 ± 0.006 1,964.00
568.375 ø 112 - 125 ± 0.006
0.90
Options: 118.00
836.535 Spare battery type V357 118.00
952.322 Extension 100 mm for Borematic ø 6 - 12 mm 128.00
952.621 Extension 150 mm for Borematic ø 12 - 20 mm 222.00
952.622 Extension 150 mm for Borematic ø 20 - 50 mm
952.623 Extension 150 mm for Borematic ø 50 - 300 mm

Sets
Sets consist of one measuring instrument with

interchangeable measuring heads and setting rings.

Item No. Measuring Setting rings Price 568.368
range/mm ø/mm EUR
Data cables Digimatic, USB Input Tool Direct,
568.924 ø 6 - 12 8, 10 2,070.00 U-WAVE available on request.
568.925 ø 12 - 25 16, 20 2,223.00
568.926 ø 25 - 50 30, 40 2,616.00
568.927 ø 50 - 100 1 62, 87 4,440.00

1 Measuring range by means of two sets of inter­change­ C04.273.EN.20240625
able measuring inserts per measuring head.

© 2024, Schut Geometrische Meettechniek bv 160 Measuring instruments and systems 2023/2024
