Schut Geometrical Metrology INTERNAL MICROMETERS

TESA Imicro digital three-point internal micrometers (continued)

The threaded cone
prevents spindle errors
(Abbe‑comparator principle).

B

A
C

Complete instruments

Item No. Measuring Accuracy Repeatability Length/mm Price
range/mm mm mm A B C EUR
1,645.00
782.530 ø 3.5 - 4 ± 0.004 0.004 2 1.5 20 1,645.00 C04.207.EN.20240625
782.531 ø 4 - 4.5 ± 0.004 0.004 2 1.5 20 1,645.00
782.532 ø 4.5 - 5.5 ± 0.004 0.004 2 1.5 25 1,645.00
782.533 ø 5.5 - 6.5 ± 0.004 0.004 2 1.5 25 1,316.00
782.534 ø 6 - 8 ± 0.004 0.004 2.5 2.5 79 1,327.00
782.535 ø 8 - 10 ± 0.004 0.004 2.5 2.5 79 1,340.00
782.536 ø 10 - 12 ± 0.004 0.004 2.5 2.5 79 1,346.00
782.537 ø 11 - 14 ± 0.004 0.004 3.5 4 93 1,354.00
782.538 ø 14 - 17 ± 0.004 0.004 3.5 4 93 1,362.00
782.539 ø 17 - 20 ± 0.004 0.004 3.5 4 93 1,368.00
782.540 ø 20 - 25 ± 0.004 0.004 7 7 91 1,383.00
782.541 ø 25 - 30 ± 0.004 0.004 7 7 91 1,402.00
782.542 ø 30 - 35 ± 0.004 0.004 7 7 91 1,416.00
782.543 ø 35 - 40 ± 0.004 0.004 7 7 91 1,469.00
782.544 ø 40 - 50 ± 0.005 0.005 11 12 104 1,492.00
782.545 ø 50 - 60 ± 0.005 0.005 11 12 104 1,534.00
782.546 ø 60 - 70 ± 0.005 0.005 11 12 104 1,564.00
782.547 ø 70 - 80 ± 0.005 0.005 11 12 104 1,600.00
782.548 ø 80 - 90 ± 0.005 0.005 11 12 104 1,629.00
782.549 ø 90 - 100 ± 0.005 0.005 11 12 104 2,531.00
782.550 ø 100 - 125 ± 0.006 0.006 26 18 100 2,539.00
782.551 ø 125 - 150 ± 0.006 0.006 26 18 100 2,546.00
782.552 ø 150 - 175 ± 0.007 0.007 26 18 100 2,557.00
782.553 ø 175 - 200 ± 0.007 0.007 26 18 100 2,868.00
782.554 ø 200 - 225 ± 0.008 0.008 26 18 100 2,918.00
782.555 ø 225 - 250 ± 0.008 0.008 26 18 100 2,968.00
782.556 ø 250 - 275 ± 0.008 0.008 26 18 100 3,018.00
782.557 ø 275 - 300 ± 0.008 0.008 26 18 100
