INTERNAL MICROMETERS Schut for Precision
Mitutoyo Holtest two-point and three-point internal micrometers
Two-point and three-point internal micrometers for quick and accurate measurement of internal
dimensions, within a large measuring range. These instruments have an improved ratchet mechanism
and the application of high-quality materials ensures a long life span.
Measuring range: ø 2 - 300 mm. ø 2 - 6 mm: two-point internal micrometers.
Graduation: 0.001 mm (ø 2 - 12 mm), Tungsten carbide cone and contact point of the spindle.
0.005 mm (ø 12 - 300 mm). Matt chrome-plated thimble.
To ø 100 mm: implementation for
Measuring Accuracy Item No. Price Item No. Price blind bores.
EUR EUR From ø 100 mm: implementation for
range/mm mm through holes.
Measuring Tungsten carbide Delivery in a plastic case or wooden
faces with with measuring faces: case with a manufacturer measuring
titanium nitride report. Sets delivered in a wooden
(TiN) coating: 368.001 1 1,075.00
ø 2 - 2.5 ± 0.002
ø 2.5 - 3 ± 0.002 368.002 1 1,075.00 carrying case with a manufacturer
ø 3 - 4 ± 0.002 368.003 1 858.00 measuring report.
ø 4 - 5 ± 0.002 368.004 1 858.00
ø 5 - 6 ± 0.002 368.005 1 858.00
ø 6 - 8 ± 0.002 368.161 408.00
ø 8 - 10 ± 0.002 368.162 397.00
ø 10 - 12 ± 0.002 368.163 397.00
ø 12 - 16 ± 0.002 368.164 480.00 368.764 384.00
ø 16 - 20 ± 0.002 368.165 493.00 368.765 390.00
ø 20 - 25 ± 0.003 368.166 505.00 368.766 393.00
ø 25 - 30 ± 0.003 368.167 517.00 368.767 420.00
ø 30 - 40 ± 0.003 368.168 535.00 368.768 464.00
ø 40 - 50 ± 0.003 368.169 543.00 368.769 473.00
ø 50 - 63 ± 0.003 368.170 611.00 368.770 523.00
ø 62 - 75 ± 0.003 368.171 638.00 368.771 536.00
ø 75 - 88 ± 0.003 368.172 650.00 368.772 549.00
ø 87 - 100 ± 0.003 368.173 665.00 368.773 581.00
ø 100 - 125 ± 0.005 368.174 973.00 368.774 899.00
ø 125 - 150 ± 0.005 368.175 1,036.00 368.775 966.00
ø 150 - 175 ± 0.005 368.176 1,104.00 368.776 1,061.00
ø 175 - 200 ± 0.005 368.177 1,143.00 368.777 1,074.00
ø 200 - 225 ± 0.005 368.178 1,202.00 368.778 1,130.00
ø 225 - 250 ± 0.005 368.179 1,234.00 368.779 1,144.00
ø 250 - 275 ± 0.005 368.180 1,285.00 368.780 1,202.00 368.002 368.168 368.770
ø 275 - 300 ± 0.005 368.181 1,416.00 368.781 1,353.00
1 Two-point internal micrometers. Extensions
Sets Item No. Extension For measuring Price
mm range/mm EUR
Measuring Extension Item No. Price Item No. Price
EUR EUR 952.322 100 ø 6 - 12 118.00
range/mm mm 952.621 150 ø 12 - 20 118.00
Measuring Tungsten carbide 952.622 150 ø 20 - 50 128.00
faces with with measuring faces: 952.623 150 ø 50 - 300 222.00
titanium nitride
ø 2 - 3 – (TiN) coating: 368.906 1 2,239.00 C04.327.EN.20240625
ø 3 - 6 – – 368.907 1 2,475.00
ø 6 - 12 100 – –
ø 12 - 20 150 368.911 1,091.00 368.991 859.00
ø 20 - 50 150 368.912 942.00 368.992 1,982.00
ø 50 - 100 150 368.913 2,160.00 368.993 2,406.00
ø 100 - 200 150 368.914 2,501.00 368.994 4,813.00
368.915 5,846.00
1 Two-point internal micrometers. 368.914
