Schut Geometrical Metrology INTERNAL MICROMETERS
Mitutoyo Holtest digital three-point internal micrometers
Digital three-point internal micrometers for quick and accurate measurement of internal
dimensions, within a large measuring range. These instruments have an improved ratchet mechanism
and the application of high-quality materials ensures a long life span.
Measuring range: ø 6 - 300 mm. To ø 100 mm: implementation for blind bores.
Resolution: 0.001 mm. From ø 100 mm: implementation for through
Measuring faces with titanium nitride (TiN) coating. holes.
Tungsten carbide cone and contact point of
Protection: IP65.
the spindle. Delivery in a plastic case or
Matt chrome-plated thimble.
Digimatic data output. wooden case with a manufacturer
Automatic switch-off. measuring report. Sets are
Reset/preset. delivered with setting rings.
Hold function. Power supply: 1 battery
type V357.
Item No. Measuring Accuracy Price 468.174
range/mm mm EUR
468.161 468.168
468.162 ø 6 - 8 ± 0.002 1,228.00
468.163 ø 8 - 10 ± 0.002 1,232.00 468.161
468.164 ø 10 - 12 ± 0.002 1,229.00
468.165 ø 12 - 16 ± 0.002 1,402.00 Extensions
468.166 ø 16 - 20 ± 0.002 1,375.00
468.167 ø 20 - 25 ± 0.003 1,445.00 Item No. Extension For measuring Price
468.168 ø 25 - 30 ± 0.003 1,445.00 mm range/mm EUR
468.169 ø 30 - 40 ± 0.003 1,434.00 952.322
468.170 ø 40 - 50 ± 0.003 1,418.00 952.621 100 ø 6 - 12 118.00
468.171 ø 50 - 63 ± 0.003 1,586.00 952.622 150 ø 12 - 20 118.00
468.172 ø 62 - 75 ± 0.003 1,565.00 952.623 150 ø 20 - 50 128.00
468.173 ø 75 - 88 ± 0.003 1,578.00 150 ø 50 - 300 222.00
468.174 ø 87 - 100 ± 0.003 1,596.00
468.175 ø 100 - 125 ± 0.005 2,081.00
468.176 ø 125 - 150 ± 0.005 2,170.00
468.177 ø 150 - 175 ± 0.005 2,271.00
468.178 ø 175 - 200 ± 0.005 2,397.00
468.179 ø 200 - 225 ± 0.005 2,534.00
468.180 ø 225 - 250 ± 0.005 2,610.00
468.181 ø 250 - 275 ± 0.005 2,686.00
ø 275 - 300 ± 0.005 2,819.00
Sets Options
Item No. Measuring Extension Price Item No. Description Price EUR
range/mm mm EUR
836.535 Spare battery type V357 0.90
One instrument with multiple measuring heads and 104.157 Mounting bracket for 62.00
extension
micrometer stand 105.00
468.971 ø 6 - 12 100 2,261.00 105.662 Digimatic data cable, 1 m 107.00
105.663 Digimatic data cable, 2 m 141.00
468.972 ø 12 - 20 150 1,853.00 106.380 USB Input Tool Direct cable, 2 m 110.00
102.791 U-WAVE data cable 187.00
468.973 ø 20 - 50 150 3,009.00 102.730 U-WAVE transmitter IP67
468.974 ø 50 - 100 150 4,309.00
468.975 ø 100 - 200 150 6,414.00
Multiple instruments 3,310.00 468.973 468.983 C04.328.EN.20240625
468.981 ø 6 - 12 3,670.00
468.982 ø 12 - 25 3,973.00
468.983 ø 25 - 50 3,064.00
468.984 ø 50 - 75 3,653.00
468.985 ø 75 - 100
