Schut Geometrical Metrology MICROMETERS

Mitutoyo special-purpose micrometers (continued)

Item No. Measuring Read-out 1 Price
range/mm mm EUR

With disk-shaped measuring faces for gear 123.101 323.250
pitch measurements:
123.101 0 - 25 0.01 (A) 269.00 169.201 369.250
123.102 25 - 50 0.01 (A) 301.00
123.103 50 - 75 0.01 (A) 331.00 117.101 317.251
123.104 75 - 100 0.01 (A) 384.00
123.105 100 - 125 0.01 (A) 405.00
123.106 125 - 150 0.01 (A) 428.00
123.107 150 - 175 0.01 (A) 457.00
123.108 175 - 200 0.01 (A) 496.00
123.109 200 - 225 0.01 (A) 507.00
123.110 225 - 250 0.01 (A) 524.00
123.111 250 - 275 0.01 (A) 550.00
123.112 275 - 300 0.01 (A) 574.00
323.250 2 0 - 25 0.001 (D) 851.00
323.251 2 25 - 50 0.001 (D) 948.00
323.252 2 50 - 75 0.001 (D) 990.00
323.253 2 75 - 100 0.001 (D) 1,027.00

With non-rotating spindle and disk-shaped 143.101 343.250
measuring faces for soft materials:
169.101 0 - 25 0.01 (A) 325.00 224.251
169.201 3 0 - 25 0.01 (A) 330.00
369.250 3 0 - 25 0.001 (D) 946.00
369.251 3 25 - 50 0.001 (D) 1,036.00
369.252 3 50 - 75 0.001 (D) 1,080.00
369.253 3 75 - 100 0.001 (D) 1,132.00

Universal, with interchangeable anvils:
117.101 0 - 25 0.01 (A) 333.00
117.102 25 - 50 0.01 (A) 421.00
317.251 2 0 - 25 0.001 (D) 711.00
317.252 2 25 - 50 0.001 (D) 791.00

With measuring jaws for hard-to-reach 126.125 326.251
places:
143.101 0 - 25 0.01 (A) 390.00 Item No. Measuring Read-out 1 Price
143.102 25 - 50 0.01 (A) 414.00 range/mm mm EUR
143.103 50 - 75 0.01 (A) 492.00
143.104 75 - 100 0.01 (A) 518.00 For thread measurements (pitch
343.250 0 - 25 0.001 (D) 915.00 diameters) 4:
343.251 25 - 50 0.001 (D) 982.00 126.125 0 - 25 0.01 (A) 371.00
343.252 50 - 75 0.001 (D) 1,037.00 126.126 25 - 50 0.01 (A) 444.00
343.253 75 - 100 0.001 (D) 1,081.00 126.127 50 - 75 0.01 (A) 494.00
126.128 75 - 100 0.01 (A) 523.00
With exchangeable ball inserts for external 126.129 100 - 125 0.01 (A) 541.00 C03.312.EN.20240625
gears 4: 126.130 125 - 150 0.01 (A) 653.00
224.251 2 0 - 25 0.001 (D) 1,027.00 326.251 2 0 - 25 0.001 (D) 874.00
224.252 2 25 - 50 0.001 (D) 1,048.00 326.252 2 25 - 50 0.001 (D) 1,073.00
224.253 2 50 - 75 0.001 (D) 1,073.00 326.253 2 50 - 75 0.001 (D) 1,100.00
224.254 2 75 - 100 0.001 (D) 1,100.00 326.254 2 75 - 100 0.001 (D) 2,095.00

1 A = analog read-out, D = digital read-out. 3 Offset measuring faces.
2 Digimatic Coolant Proof (IP65) model. 4 Measuring inserts separately available.
