DEPTH MICROMETERS Schut for Precision

Digital depth micrometers IP65

Digital depth micrometers with interchangeable, spherical rods or flat rods. With the flat rods
mainly flat and spherical surfaces can be measured very accurately. The spherical rods are especially
suitable for beveled and hollow surfaces. The high accuracy of the rods makes resetting after
exchanging the rods unnecessary. Two models with different base lengths available.

 Measuring range: 0 - 300 mm.  Preset.
 Resolution: 0.001 mm.  Measuring rods: ø 4.5 mm.
 mm/inch conversion.  Locking screw.
 ABS/INC switchable.  Protection: IP65.
 Automatic switch-off.  Power supply: 1 battery type V357.

909.765

Model with spherical rods especially for hollow and beveled surfaces

Item No. Price Item No. Price Measuring Accuracy Number
EUR EUR range/mm mm of rods
1
Base 63 mm: Base 101.5 mm: 0 - 25 ± 0.005 2
909.753 156.00 909.759 156.00 0 - 50 ± 0.005 4
909.754 163.00 909.760 163.00 0 - 100 ± 0.006 6
909.755 178.00 909.761 178.00 0 - 150 ± 0.007 8
909.756 192.00 909.762 192.00 0 - 200 ± 0.008 12
909.757 207.00 909.763 207.00 0 - 300 ± 0.009
909.758 243.00 909.764 243.00 Number
of rods
Model with flat rods especially for flat and spherical surfaces 1
2
Item No. Price Item No. Price Measuring Accuracy 4
EUR EUR range/mm mm 6
8
Base 63 mm: Base 101.5 mm: 0 - 25 ± 0.005 12
909.765 156.00 909.771 156.00 0 - 50 ± 0.005
909.766 163.00 909.772 163.00 0 - 100 ± 0.006
909.767 178.00 909.773 178.00 0 - 150 ± 0.007
909.768 192.00 909.774 192.00 0 - 200 ± 0.008
909.769 207.00 909.775 207.00 0 - 300 ± 0.009
909.770 243.00 909.776 243.00

Option

Item No. Description Price EUR C02.280.EN.20240625

836.535 Spare battery type V357 0.90

© 2024, Schut Geometrische Meettechniek bv 136 Measuring instruments and systems 2023/2024
