Schut Geometrical Metrology DEPTH MICROMETERS

Depth micrometers

Depth micrometers with interchangeable, spherical or flat rods. With the flat rods mainly flat and
spherical surfaces can be measured very accurately. The spherical rods are especially suitable for
beveled and hollow surfaces. The high accuracy of the rods makes recalibration after exchanging the
rods unnecessary. Two models with different base lengths available.

 Measuring range: 0 - 300 mm.  Measuring rods: ø 4.5 mm.
 Graduation: 0.01 mm.  Locking screw.

906.970

906.040

Model with spherical rods especially for hollow and beveled surfaces

Item No. Price Item No. Price Measuring Accuracy Number
EUR EUR range/mm mm of rods
1
Base 63 mm: 45.00 Base 101.5 mm: 0 - 25 ± 0.005 2
906.964 906.040 45.00 0 - 50 ± 0.005 4
906.965 54.00 906.039 54.00 0 - 100 ± 0.006 6
906.966 68.00 906.041 68.00 0 - 150 ± 0.007 8
906.967 88.00 906.042 88.00 0 - 200 ± 0.008 12
906.968 127.00 906.043 127.00 0 - 300 ± 0.009
906.969 176.00 906.044 176.00 Number
of rods
Model with flat rods especially for flat and spherical surfaces 1
2
Item No. Price Item No. Price Measuring Accuracy 4
EUR EUR range/mm mm 6
8
Base 63 mm: Base 101.5 mm: ± 0.005 12
906.970 64.00 906.976 64.00 0 - 25 ± 0.005
906.971 76.00 906.977 76.00 0 - 50 ± 0.006
906.972 106.00 906.978 106.00 0 - 100 ± 0.007
906.973 127.00 906.979 127.00 0 - 150 ± 0.008
906.974 157.00 906.980 157.00 0 - 200 ± 0.009 C02.275.EN.20250106
906.975 206.00 906.981 206.00 0 - 300
