P. 140
MICROMETER HEADS Schut for Precision
Digital micrometer heads
Several digital micrometer heads with different possibilities.
Measuring range: 0 - 50 mm. Memory absolute measuring value.
Resolution: 0.001 mm. Preset for ABS measurement.
Accuracy: ± 0.003 mm Friction thimble.
Power supply: 1 battery type V357 or
(909.900/901: ± 0.005 mm).
mm/inch conversion. 1 battery type CR2032.
ABS/INC switchable.
On/off switch.
Automatic switch-off.
L2 (max) L1 909.897
Item No. Measuring Dimensions/mm Description Price
range/mm spindle clamping L1 L2 measuring faces EUR
With IP65 protection: ø 6.5 ø 12 x 17.5 115 46 flat, tungsten carbide measuring face 109.00
909.897 0 - 25 ø 6.5 ø 12 x 17.5 115 46 spherical 109.00
909.898 0 - 25 ø 6.5 ø 12 x 17.5 116 56 flat, non-rotating tip 111.00
909.899 0 - 25 ø 7.5 ø 12 x 35.5 140 89 flat, tungsten carbide measuring face 174.00
909.900 0 - 50 ø 7.5 ø 12 x 35.5 140 89 spherical 174.00
909.901 0 - 50
With non-rotating spindle: flat, tungsten carbide measuring face 142.00
909.902 0 - 25 ø 7.5 ø 12 x 10 124 39 interchangeable measuring inserts 145.00
909.903 0 - 25 ø 7.5 ø 12 x 10 123 39
Options: 0.90
836.535 Battery type V357 0.50
495.157 Battery type CR2032
Interchangeable measuring inserts for 909.903 No. Item No. Description Price
measuring faces EUR
1 ø6.5 15 ø5 0.7 5
2 ø6.5 4.5 ø0.3 60° 6 Measuring inserts, per pair: 15.90
3 ø2 0.35 60° 7 906.788 flat 19.00
SR 5 906.789 spherical 28.60
4 906.790 small 28.60
906.791 disc 38.00
4 ø12 906.792 knife/flat 28.60 C03.317.EN.20250106
906.793 point 48.00
906.794 knife 161.00
906.795 Set of 7 pairs
