MICROMETER HEADS Schut for Precision
Mitutoyo Digimatic micrometer heads IP65
These digital micrometer heads have an ergonomic design and a high protection degree against
water jets (IP65).
Measuring range: 0 - 25 mm. 350.271
Resolution: 0.001 mm. 350.272
ABS/INC switchable.
Digimatic data output.
Reset/preset.
Hold function.
Non-rotating spindle (only 350.261).
Protection: IP65.
Resistant to workshop conditions.
Conforms to factory standard.
Power supply: 1 battery type V357.
Data cables Digimatic, USB Input Tool Direct,
U-WAVE available on request.
Item No. Measuring range/mm Accuracy/mm Spindle ø/mm Clamp nut Price EUR
± 0.002 6.35 no 556.00
350.261 0 - 25 ± 0.002 6.35 no 516.00
350.271 0 - 25 ± 0.002 6.35 yes 529.00
350.272 0 - 25
Option: 0.90
836.535 Spare battery type V357
Mitutoyo Digimatic micrometer head
Digital micrometer head with non-rotating spindle for integration into machinery and measuring
systems such as XY measuring tables of microscopes and projectors. The display and operating unit
is rotatable over 330° and guarantees an ideal read-out in any position.
Measuring range: 0 - 50 mm. Clamping stem without clamp nut.
Resolution: 0.001 mm. Non-rotating spindle.
ABS/INC switchable. Reversible measuring direction.
LCD display 330° rotatable. Lapped tungsten carbide measuring face: ø 8 mm.
Digimatic data output. Conforms to factory standard.
On/off switch. Power supply: 1 battery
Reset/preset.
type V357.
Data cables Digimatic, USB Input Tool Direct,
U-WAVE available on request.
Item No. Measuring Accuracy Spindle Price C03.288.EN.20240625
range/mm mm ø/mm EUR
946.00
164.163 0 - 50 ± 0.003 8
Option: 0.90
836.535 Spare battery type V357
