Schut Geometrical Metrology MICROMETER HEADS
Mitutoyo micrometer heads 148.216
Measuring range: 0 - 25 mm. 148.103
Graduation: 0.01 or 0.02 mm. 149.131
Clamping stem: with or without clamp nut.
Conforms to factory standard.
Many models available, like:
– with reversed reading,
– with rotating or non-rotating spindle,
– with spindle lock,
– with large thimble diameter,
for easy reading.
L2 (zero position) L1 (zero position)
Spindle D1
149.183
Item No. Measuring Graduation Accuracy Clamp Dimensions/mm Price
range/mm mm mm nut spindle D1 L1 L2 EUR
For general applications: ± 0.002 no ø 5 ø 13 31.5 27 63.00
148.104 0 - 13 0.01 ± 0.002 yes ø 5 ø 13 31.5 27 68.00
148.103 0 - 13 0.01
For general applications with spherical measuring face:
148.801 0 - 13 0.01 ± 0.002 no ø 5 ø 13 31.5 27 64.00
148.802 0 - 13 0.01 ± 0.002 yes ø 5 ø 13 31.5 27 69.00
Ultra-small micrometer heads with spherical measuring face:
148.215 0 - 5 0.02 ± 0.005 no ø 2 ø 6 20.5 11.5 120.00
148.216 0 - 5 0.02 ± 0.005 yes ø 2 ø 6 20.5 11.5 124.00
148.205 0 - 6.5 0.01 ± 0.005 no ø 3.5 ø 9 21.7 15 63.00
148.207 0 - 6.5 0.01 ± 0.005 yes ø 3.5 ø 9 21.7 15 67.00
With lapped tungsten carbide measuring face: no ø 6.35 ø 15 43.5 32 72.00
149.132 0 - 15 0.01 ± 0.002 yes ø 6.35 ø 15 43.5 32 75.00
149.131 0 - 15 0.01 ± 0.002
With lapped tungsten carbide spherical measuring face:
149.801 0 - 15 0.01 ± 0.002 no ø 6.35 ø 15 43.5 32 80.00
149.802 0 - 15 0.01 ± 0.002 yes ø 6.35 ø 15 43.5 32 83.00
With lapped tungsten carbide measuring face, with spindle lock:
149.183 0 - 15 0.01 ± 0.002 no ø 6.35 ø 15 49 26.5 85.00
149.184 0 - 15 0.01 ± 0.002 yes ø 6.35 ø 15 49 26.5 91.00
With lapped tungsten carbide measuring face, with ratchet:
150.192 0 - 25 0.01 ± 0.002 no ø 6.35 ø 18 67 42 72.00
150.191 0 - 25 0.01 ± 0.002 yes ø 6.35 ø 18 67 42 84.00
With lapped tungsten carbide spherical measuring face, with ratchet: C03.308.EN.20250106
150.801 0 - 25 0.01 ± 0.002 no ø 6.35 ø 18 67 42 85.00
150.802 0 - 25 0.01 ± 0.002 yes ø 6.35 ø 18 67 42 92.00
