Schut Geometrical Metrology MICROMETER ACCESSORIES
Setting gauges Setting standards
Cylindrical gauges for micrometers with flat Cylindrical setting standards for micrometers
parallel measuring faces. with prism-shaped anvil.
Measuring faces L < 100 mm: ø 7 mm, flat,
L < 300 mm: ø 8 mm, flat,
L ≥ 300 mm: ø 8 mm, spherical.
With plastic insulating grip.
Larger sizes available on request.
907.464 909.326
Item No. Length Accuracy Price Item No. Diameter/mm Price EUR
mm µm EUR 909.323 5 12.80
4.80 909.324 37.80
907.464 25 ± 2 5.50 909.325 20 42.00
907.465 50 ± 2 6.90 909.326 25 44.00
907.466 75 ± 2.5 8.90 909.327 35 46.00
907.467 100 ± 2.5 11.10 909.328 45 54.00
907.468 125 ± 3 12.50 909.329 50 76.00
907.469 150 ± 3 14.50 909.330 65 102.00
907.470 175 ± 3.5 16.60 909.331 80 110.00
907.471 200 ± 4 18.50 85
907.472 225 ± 4 21.20
907.473 250 ± 4 23.10 Setting standards
907.474 275 ± 4.5 45.00
907.475 300 ± 4.5 45.00 Hardened steel setting standards for threads
907.476 325 ± 5 54.00 with 55° or 60° flank angle.
907.477 350 ± 5 45.00
907.478 375 ± 5.5 54.00 909.305
907.479 400 ± 5.5 48.00
907.480 425 ± 6 58.00 Item No. Length/mm Price EUR
907.481 450 ± 6 48.00
907.482 475 ± 6.5 58.00 For threads with 60° flank angle: 43.00
907.483 500 ± 6.5 59.00 909.304 25 50.00
907.484 525 ± 7 59.00 909.305 50 57.00
907.485 575 ± 7.5 70.00 909.306 75 66.00
907.486 625 ± 7.5 70.00 909.307 100 76.00
907.487 675 ± 8 79.00 909.308 125 87.00
907.488 725 ± 8.5 79.00 909.309 150 100.00
907.489 775 ± 9.5 91.00 909.310 175 115.00
907.490 825 ± 10 91.00 909.311 200
907.491 875 ± 10.5 111.00
907.492 925 ± 11 111.00 For threads with 55° flank angle:
907.493 975 ± 11.5 155.00 909.312 25 43.00
907.494 1050 ± 12 155.00 909.313 50 50.00
907.495 1150 ± 13 187.00 909.314 75 57.00
907.496 1250 ± 14 187.00 909.315 100 66.00
907.497 1350 ± 15 223.00 909.316 125 76.00
907.498 1450 ± 16 223.00 909.317 150 87.00
909.529 1 1550 ± 17 268.00 909.318 175 100.00 C03.219.EN.20240625
909.530 1 1650 ± 18 268.00 909.319 200 115.00
909.531 1 1750 ± 19 321.00
909.532 1 1850 ± 20 321.00
909.533 1 1950 ± 21
