MICROMETERS Schut for Precision

Thread measuring wires

For measuring external threads using the three-wire method. The flank diameter can be determined
according to the measured diameter, using tables.
 For micrometers with measuring faces ø 6.35,

ø 6.5 or ø 8 mm. (Also available for measuring
faces ø 6.8 and ø 7.5 mm.)
 Very high measuring accuracy: ± 0.001 mm.
 In pairs or in a set.
 The wire holders are held in position on the
anvil and spindle by a spring clamp.
 The wires are mounted on the holder in
such a way that they position themselves
on the thread.

d2 dD
M
C03.244.EN.20250106
Thread measuring wires for micrometers with measuring faces ø 6.35, ø 6.5 or ø 8 mm

ø 6.35 mm ø 6.5 mm ø 8 mm Wire Metric, W hitworth, UN/UNC/UNF,
Item No. Price Item No. Price Item No. Price diameter
EUR EUR EUR dD/mm pitch threads threads

in mm per inch per inch

833.442 164.00 779.161 164.00 836.689 164.00 0.17 0.25; 0.3 – –
833.443 164.00 781.651 164.00 836.690 164.00 0.195 80
833.444 164.00 779.162 164.00 836.691 164.00 0.22 – – 72
833.445 164.00 779.163 164.00 835.844 164.00 0.25 64
833.446 164.00 779.164 164.00 834.499 164.00 0.29 0.35 – 56
833.447 164.00 779.165 164.00 834.498 164.00 0.335 48; 44
833.448 164.00 781.652 164.00 837.848 164.00 0.390 0.4 – 40
833.449 164.00 779.166 164.00 833.872 164.00 0.455 36
833.450 164.00 779.167 164.00 834.585 164.00 0.53 0.45; 0.5 – 32; 28
833.451 164.00 779.168 164.00 834.480 164.00 0.62 24
833.452 164.00 779.169 164.00 834.586 164.00 0.725 0.6 40 20
833.453 164.00 779.170 164.00 834.290 164.00 0.895 18; 16
833.454 164.00 779.171 164.00 834.502 164.00 1.10 – – 14; 13
833.455 164.00 779.172 164.00 834.291 164.00 1.35 12; 11
833.456 164.00 779.173 164.00 833.871 164.00 1.65 0.7 - 0.8 – 10; 9
833.457 164.00 779.174 164.00 834.292 164.00 2.05 8; 7
833.458 164.00 779.175 164.00 834.416 164.00 2.55 – 32; 28 6
833.459 164.00 779.176 164.00 834.483 164.00 3.20 5; 4.5
837.501 512.00 837.642 512.00 834.509 512.00 4.00 1 26; 24 4

1.25 22; 20; 19

1.5 18; 16

1.75 14

2 12; 11

2.5 10; 9

3.0; 3.5 8; 7

4.0; 4.5 6

5.0; 5.5 5; 4.5

6.0 4; 3.5

834.580 3,040.00 779.160 3,040.00 834.581 3,040.00 Set with wire diameters 0.17 to 3.20 mm
