Schut Geometrical Metrology MICROMETERS

Screw thread micrometers (continued)

Measuring inserts for screw thread micrometers with clamping shaft ø 5 mm.

Item No. Threads per inch Price EUR

Measuring inserts for Whitworth threads,
55° flank angle, per pair:
906.730 60 - 48 23.80
906.731 48 - 40 23.80
906.732 40 - 32 23.80
906.725

906.733 32 - 24 23.80
906.734 24 - 18 23.80
906.735 18 - 14 23.80
906.736 14 - 10 23.80
906.737 10 - 7.0 23.80
906.738 7.0 - 4.5 23.80
906.739 4.5 - 3.5 23.80

906.740 Set 60 - 3.5 186.00

Item No. Pitch/mm Price EUR Item No. Threads per inch Price EUR

Measuring inserts for metric threads, Measuring inserts for UN, UNC and UNF
60° flank angle, per pair: threads, 60° flank angle, per pair:
906.720 0.4 - 0.5 23.80 906.741 64 - 48 23.80
906.721 0.6 - 0.9 23.80 906.742 44 - 28 23.80
906.722 1.0 - 1.75 23.80 906.743 24 - 14 23.80
906.723 2.0 - 3.0 23.80 906.744 13 - 9 23.80
906.724 3.5 - 5.0 23.80 906.745 8 - 5 23.80
906.725 5.5 - 7.0 23.80 906.746 4.5 - 3.5 23.80

906.726 Set 0.4 - 7.0 111.00 906.747 Set 64 - 3.5 111.00

909.305

Item No. Length/mm Price EUR Item No. Length/mm Price EUR

Hardened steel setting standards for threads Hardened steel setting standards for threads
with 60° flank angle: with 55° flank angle:
909.304 25 43.00 909.312 25 43.00
909.305 50 50.00 909.313 50 50.00
909.306 75 57.00 909.314 75 57.00
909.307 100 66.00 909.315 100 66.00
909.308 125 76.00 909.316 125 76.00
909.309 150 87.00 909.317 150 87.00
909.310 175 100.00 909.318 175 100.00 C03.241.EN.20250106
909.311 200 115.00 909.319 200 115.00
