MICROMETERS                                                                        Schut for Precision

Screw thread micrometers (continued)

Measuring inserts for screw thread micrometers with clamping shaft ø 5 mm.

                                                            Item No. Threads per inch Price EUR

                                                            Measuring inserts for Whitworth threads,
                                                            55° flank angle, per pair:
                                                            906.730 	  60	 -	48                  23.80
                                                            906.731 	  48	 -	40                  23.80
                                                            906.732 	  40	 -	32                  23.80
                            906.725

                                                            906.733 	  32	 -	24                  23.80
                                                            906.734 	  24	 -	18                  23.80
                                                            906.735 	  18	 -	14                  23.80
                                                            906.736 	  14	 -	10                  23.80
                                                            906.737 	  10	 -	 7.0                23.80
                                                            906.738 	  7.0	-	 4.5                23.80
                                                            906.739 	  4.5	-	 3.5                23.80

                                                            906.740 Set 60 - 3.5                 186.00

Item No.   Pitch/mm                         Price EUR       Item No. Threads per inch Price EUR

Measuring inserts for metric threads,                       Measuring inserts for UN, UNC and UNF
60° flank angle, per pair:                                  threads, 60° flank angle, per pair:
906.720 	    0.4	-	0.5                      23.80           906.741 	  64	 -	48                  23.80
906.721 	    0.6	-	0.9                      23.80           906.742 	  44	 -	28                  23.80
906.722 	    1.0	-	1.75                     23.80           906.743 	  24	 -	14                  23.80
906.723 	    2.0	-	3.0                      23.80           906.744 	  13	 -	 9                  23.80
906.724 	    3.5	-	5.0                      23.80           906.745 	  8	 -	 5                   23.80
906.725 	    5.5	-	7.0                      23.80           906.746 	  4.5	-	 3.5                23.80

906.726 Set 0.4 - 7.0                       111.00          906.747 Set 64 - 3.5                 111.00

                                                            909.305

Item No.   Length/mm                        Price EUR       Item No.   Length/mm        Price EUR

Hardened steel setting standards for threads                Hardened steel setting standards for threads
with 60° flank angle:                                       with 55° flank angle:
909.304 	              25                   43.00           909.312 	             25             43.00
909.305 	              50                   50.00           909.313 	             50             50.00
909.306 	              75                   57.00           909.314 	             75             57.00
909.307 	    100                            66.00           909.315 	  100                       66.00
909.308 	    125                            76.00           909.316 	  125                       76.00
909.309 	    150                            87.00           909.317 	  150                       87.00
909.310 	    175                            100.00          909.318 	  175                       100.00            C03.241.EN.20250321
909.311 	    200                            115.00          909.319 	  200                       115.00
