Schut Geometrical Metrology MICROMETERS

Micrometers with prism-shaped anvil

Analog and digital micrometers with prism-shaped anvil for measuring the diameters of objects with
an odd number of flutes such as taps, reamers and mills. The angle of the prism aperture is designed
for 3‑, 5‑ or 7‑fluted workpieces.

 Measuring range: 1 - 105 mm. Digital
 Analog: graduation 0.01 mm,  mm/inch conversion.
 ABS/INC switchable.
digital: resolution 0.001 mm.  Automatic switch-off.
 Spindle: ø 6.5 mm.  Reset/preset.
 Tungsten carbide measuring faces. The  Protection: IP65.
 Power supply: 1 battery type V357.
906.160 and 909.866 have a pointed spindle
for the smallest objects.
 V‑groove for:
3‑fluted objects: 60°,
5‑fluted objects: 108°,
7‑fluted objects: 128° 34' 17".
 Delivery in a plastic case, with a setting
standard.

909.866

906.161

Item No. Measuring Accuracy Price Item No. Price
range/mm mm EUR EUR

For 3‑fluted objects (60°), analog: Digital: 221.00 Setting standards
906.160 1 - 15 ± 0.004 142.00 909.866 226.00
906.161 5 - 20 ± 0.004 148.00 909.867 247.00 Item No. ø Price
906.162 20 - 35 ± 0.005 177.00 909.868 278.00 mm EUR
906.163 35 - 50 ± 0.005 218.00 909.869 282.00
906.164 50 - 65 ± 0.006 234.00 909.870 296.00
906.165 65 - 80 ± 0.006 253.00 909.871 311.00
907.060 80 - 95 ± 0.007 273.00 909.872

For 5‑fluted objects (108°), analog: Digital: 225.00 909.323 5 12.80
906.166 5 - 25 ± 0.004 147.00 909.873 256.00 909.324 20 37.80
906.167 25 - 45 ± 0.005 189.00 909.874 277.00 909.325 25 42.00
906.168 45 - 65 ± 0.006 218.00 909.875 303.00 909.326 35 44.00
906.169 65 - 85 ± 0.007 253.00 909.876 329.00 909.327 45 46.00
907.061 85 - 105 ± 0.008 288.00 909.877 909.328 50 54.00
909.329 65 76.00
For 7‑fluted objects (128° 34' 17"), analog: Digital: 909.330 80 102.00
906.170 5 - 25 ± 0.004 147.00 909.878 225.00 909.331 85 110.00
906.171 25 - 45 ± 0.005 189.00 909.879 256.00
906.172 45 - 65 ± 0.006 218.00 909.880 277.00
906.173 65 - 85 ± 0.007 253.00 909.881 303.00
Option:
C03.233.EN.20240625
836.535 Spare battery type V357 0.90 909.326
