PLUG GAUGES www.promet.se
Plug gauges
Ground and lapped, hardened tool steel plug gauges with a Per piece Price SEK
high accuracy. Available per piece and in sets. Swiss made. Diameter/mm 430.80
0.06 - 0.09 339.60
Diameter range: ø 0.06 - 10.00 mm. 0.10 - 0.19 309.60
Increment: 0.01 mm. 0.20 - 0.29 195.60
Accuracy: ± 0.0005 mm. 0.30 - 0.49 189.60
Hardened tool steel (HV 760 ± 50). 0.50 - 0.99 189.60
1.00 - 2.99 248.40
Ground and lapped. 3.00 - 5.99 338.40
Measuring length (and total length): 6.00 - 10.00
ø 0.06 - 0.30 mm: 2 mm (34 mm), Sets Diameter Pieces Price
ø 0.31 - 0.50 mm: 3.5 mm (35.5 mm), Item No. mm SEK
ø 0.51 - 1.50 mm: 5 mm (37 mm),
ø 1.51 - 2.00 mm: 6 mm (38 mm), 833.761 0.06 - 0.50 45 14,112.00
ø 2.01 - 3.50 mm: 8 mm (43 mm), 833.762 0.51 - 1.00 50 11,124.00
ø 3.51 - 6.00 mm: 10 mm (55 mm), 833.763 1.01 - 1.50 50 10,884.00
ø 6.01 - 8.00 mm: 14 mm (59 mm), 833.764 1.51 - 2.00 50 10,884.00
ø 8.01 - 10.00 mm: 18 mm (63 mm). 833.765 2.01 - 2.50 50 10,884.00
Size indication on the insulated handle. 833.766 2.51 - 3.00 50 10,884.00
Also available in tungsten carbide and 833.767 3.01 - 3.50 50 13,212.00
ceramic with an accuracy of ± 0.001 mm. 833.768 3.51 - 4.00 50 13,212.00
837.311 4.01 - 4.50 50 13,212.00
837.312 4.51 - 5.00 50 13,212.00
837.313 5.01 - 5.50 50 13,212.00
837.314 5.51 - 6.00 50 13,212.00
837.315 6.01 - 6.50 50 18,816.00
837.316 6.51 - 7.00 50 18,816.00
837.317 7.01 - 7.50 50 18,816.00
837.318 7.51 - 8.00 50 18,816.00
837.319 8.01 - 8.50 50 18,816.00
837.320 8.51 - 9.00 50 18,816.00
837.321 9.01 - 9.50 50 18,816.00
837.322 9.51 - 10.00 50 18,816.00
Select setting rings 830.001 Item No. Size/mm Price SEK C12.302.Promet.20240517
830.001 1 2,628.00
Setting rings, manufactured according 830.002 1.2 2,280.00
DIN 2250 form C, 1 to 4 mm. 830.003 1.5 2,196.00
830.004 1.8 2,124.00
The size is indicated on the ring to three 830.005 2 2,256.00
decimal places. 830.006 2.2 1,992.00
830.007 2.5 2,100.00
For all gauges also measuring reports 830.008 2.8 1,848.00
can be ordered. 830.009 3 840.00
830.010 4 475.20
830.003 830.007 830.009
