LMW taper gauges

To increase the already large capacity to transmit moments, some taper gauges are furnished with a
lip which functions as catch lock.

832.560

832.539

Morse taper gauges 832.540 832.561

Indica- Without lip, DIN 229 Price With lip, DIN 230 Price
tion Item No. Price Item No. SEK Item No. Price Item No. SEK
Morse SEK SEK

Plug: Ring: 2,412.00 Plug: Ring:
0 832.531 960.00 832.532 2,352.00 832.552 1,392.00 832.553 3,756.00
1 832.533 1,008.00 832.534 2,292.00 832.554 1,428.00 832.555 3,684.00
2 832.535 1,128.00 832.536 2,772.00 832.556 1,620.00 832.557 3,612.00
3 832.537 1,344.00 832.538 3,432.00 832.558 1,968.00 832.559 4,332.00
4 832.539 1,692.00 832.540 4,644.00 832.560 2,412.00 832.561 5,352.00
5 832.541 2,508.00 832.542 7,344.00 832.562 3,384.00 832.563 7,224.00
6 832.543 3,396.00 832.544 832.564 4,968.00 832.565 11,856.00

Metric taper gauges

Indica- Without lip, DIN 234 Price With lip, DIN 235 Price
tion Item No. Price Item No. SEK Item No. Price Item No. SEK
metric SEK SEK

Plug: Ring: Plug: Ring:
4 804.001 1,248.00 804.011 3,864.00 – –
6 804.002 1,248.00 804.012 3,864.00 – –
80 804.003 5,988.00 804.013 12,612.00 804.021 7,860.00 804.031 20,520.00
100 804.004 9,360.00 804.014 16,980.00 804.022 12,360.00 804.032 27,840.00
120 804.005 14,040.00 804.015 26,640.00 804.023 17,856.00 804.033 39,720.00

Short taper gauges

Indica- Plug, DIN 2079 Ring, DIN 2080
tion Item No. Price Item No. Price
SK SEK SEK
832.569 3,492.00
30 832.568 2,172.00 832.571 4,572.00 832.568 C12.206.Promet.20240517
40 832.570 2,652.00 832.573 7,584.00
50 832.572 3,732.00 832.575 12,888.00 832.571
60 832.574 7,524.00
