www.promet.se PIN GAUGES
Pin gauges in sets
Hardened steel pin gauges in sets with favourable price-performance ratio, very well suited for
workshop use. Delivery in plastic case with a declaration of conformity and holder for Go/NoGo
determination.
Hardened steel.
Diameter range: 0.20 - 20.00 mm.
Increment: 0.01 mm or 0.1 mm.
Accuracy: ± 0.003 mm.
Without handle.
Pin gauges > ø 1.5 mm with size indication.
Length: 50 mm.
Delivery in a plastic carrying case with a
declaration of conformity with pin gauges in
separate plastic tubes with size indication.
Delivery with holder with Go/NoGo
indication.
Item No. Diameter Increment Number Price
mm mm per set SEK
910.367 0.20 - 10.00 0.1 99 1,956.00 910.195
910.368 10.00 - 20.00 0.1 101 3,636.00
910.213
910.193 0.50 - 1.00 0.01 51 1,392.00 910.379
910.194 1.00 - 2.00 0.01 101 1,752.00 910.378
910.195 2.00 - 3.00 0.01 101 1,752.00 Promet Precision 2023/2024-D
910.196 3.00 - 4.00 0.01 101 1,752.00
910.197 4.00 - 5.00 0.01 101 1,752.00
910.198 5.00 - 6.00 0.01 101 1,968.00
910.199 6.00 - 7.00 0.01 101 1,968.00
910.200 7.00 - 8.00 0.01 101 1,968.00
910.201 8.00 - 9.00 0.01 101 1,968.00
910.202 9.00 - 10.00 0.01 101 1,968.00
910.203 10.00 - 11.00 0.01 101 2,652.00
910.204 11.00 - 12.00 0.01 101 3,000.00
910.205 12.00 - 13.00 0.01 101 3,000.00
910.206 13.00 - 14.00 0.01 101 3,000.00
910.207 14.00 - 15.00 0.01 101 3,132.00
910.208 15.00 - 16.00 0.01 101 3,180.00
910.209 16.00 - 17.00 0.01 101 4,164.00
910.210 17.00 - 18.00 0.01 101 4,164.00
910.211 18.00 - 19.00 0.01 101 4,164.00
910.212 19.00 - 20.00 0.01 101 5,520.00
Holders for Go/NoGo determination: 201.60
910.213 Pin gauge handle
201.60
Go-NoGo 0.5-13 mm
910.214 Pin gauge handle 201.60
249.60
Go-NoGo 13-20 mm 309.60
370.80
Holders for Go/NoGo determination: 438.00
492.00
910.378 0.30 - 1.50
910.379 1.20 - 6.50
910.380 5.00 - 14.00 C12.306.Promet.20240517
910.381 12.00 - 16.50
910.382 14.00 - 19.50
910.383 18.00 - 22.00
