Plug gauges H7
Manufactured according DIN EN ISO 1938. Available from 1 to 100 mm with Go and NoGo on
one handle.
DIN 7162 and 7164.
H7 fit size in hardened steel.
With serial number.
Delivery with a manufacturer measuring report.
Individual plug gauges delivered in a plastic
tube. Set delivered in a plastic case.
Including wear allowance at the Go end.
Wear allowance
New gauges are supplemented with a wear
allowance on the Go end: z (plus) for plug gauges.
Accordingly, the size indicated on the handle is not
similar to the measured value of the new Go end.
Item No. Size H7 Price Item No. Size H7 Price Item No. Size H7 Price
mm SEK mm SEK mm SEK
911.000 1 379.20 911.023 19 220.80 911.047 47 552.00
911.001 1.5 340.80 911.024 20 243.60 911.048 48 552.00
911.002 2 195.60 911.025 21 243.60 911.049 50 552.00
911.003 2.5 181.20 911.026 22 243.60 911.050 52 648.00
911.004 3 181.20 911.027 23 244.80 911.051 55 648.00
911.005 3.5 181.20 911.028 24 244.80 911.052 58 696.00
911.006 4 181.20 911.029 25 244.80 911.053 60 696.00
911.007 4.5 181.20 911.030 26 277.20 911.054 62 696.00
911.008 5 181.20 911.031 27 277.20 911.055 65 864.00
911.009 5.5 181.20 911.032 28 277.20 911.056 68 876.00
911.010 6 146.40 911.033 30 309.60 911.057 70 912.00
911.011 7 163.20 911.034 32 309.60 911.058 72 912.00
911.012 8 163.20 911.035 33 331.20 911.059 75 1,008.00
911.013 9 163.20 911.036 34 340.80 911.060 78 1,008.00
911.014 10 163.20 911.037 35 360.00 911.061 80 1,056.00
911.015 11 175.20 911.038 36 360.00 911.062 82 1,260.00
911.016 12 175.20 911.039 37 360.00 911.063 85 1,260.00
911.017 13 175.20 911.040 38 360.00 911.064 88 1,260.00
911.018 14 175.20 911.041 40 360.00 911.065 90 1,344.00
911.019 15 192.00 911.042 42 438.00 911.066 92 1,380.00
911.020 16 201.60 911.043 44 492.00 911.067 95 1,416.00
911.021 17 201.60 911.044 45 552.00 911.068 98 1,524.00
911.022 18 201.60 911.045 46 552.00 911.069 100 1,572.00
Set plug gauges Price SEK
1,236.00
Item No. Description C12.307.Promet.20240517
911.157 Plug gauges (Go + NoGo) H7: 3, 4, 5, 6, 8, 10, 12 mm
