DEPTH CALIPERS Schut for Precision

Digital lightweight depth caliper

Universal lightweight aluminum depth caliper with two interchangeable measuring inserts set at 90°
and 3 measuring bases. All inserts with M2.5 thread can be used with these calipers. Please see the dial
indicator accessories section for these inserts. Excellent sliding properties due to double prismatic joint.

 Measuring range: 0 - 500 mm.  Interchangeable measuring inserts:
 Resolution: 0.01 mm. 2 measuring inserts included (ball
 mm/inch conversion. attachments ø 3.2 mm, l = 6 mm and ø 5 mm,
 On/off switch. l = 12 mm).
 Reset.
 Length included measuring bases: 150, 300  Locking screw.
 Delivery in a plastic case with a manufacturer
and 450 mm.
measuring report.
 Power supply: 1 battery type V357.

Item No. Measuring Accuracy Weight Price
range/mm mm kg EUR
0.5 440.00
853.210 0 - 500 0.05 853.210
0.90
Option:
836.535 Spare battery type V357

Digital lightweight depth calipers with with round depth rod

Universal lightweight aluminum depth calipers with round depth rod and M2.5 threaded hole for
interchangeable inserts. Inserts with M2.5 thread can be used with these calipers. Please see the dial
indicator accessories section for these inserts. Excellent sliding properties due to double prismatic joint.

 Measuring range: 0 - 500 mm. 853.214
 Diameter depth rod:
Item No. Measuring Accuracy Weight Price
Measuring range 0 - 300 mm ø 4 mm range/mm mm kg EUR
Measuring range 500 mm ø 6 mm. 853.212
 Resolution: 0.01 mm. 853.213 0 - 200 0.03 0.3 337.00
 mm/inch conversion. 853.214 0 - 300 0.04 0.4 450.00
 On/off switch. 0 - 500 0.05 0.6 562.00
 Reset. Options:
 Length included measuring base: 836.535 Spare battery type V357 0.90
350 mm. 853.222 Measuring base 550 mm 227.00
 Interchangeable measuring inserts: 853.223 Measuring base 750 mm 334.00
2 measuring inserts included (ball attachment 853.224 Measuring base 950 mm 489.00
ø 3.2 mm, l = 6 mm
and disc attachment ø 10 mm, d = 2 mm C02.339.
at 0 - 300 mm
or disc attachment ø 20 mm, d = 2 mm
at 500 mm).
 Locking screw.
 Delivery in a plastic case with a
manufacturer measuring report.
 Power supply: 1 battery type V357.
