P. 86
DEPTH CALIPERS Schut for Precision
Mitutoyo Absolute Digimatic depth calipers
Mitutoyo depth calipers with the Absolute measuring system. For use in workshop conditions,
Mitutoyo has also developed Coolant Proof models with high protection degree (IP67); these are
resistant to oil and coolants, and even last temporary immersion.
Measuring range: 0 - 1000 mm. Beam: 16 x 3.5 mm.
Resolution: 0.01 mm. Protection: IP67
ABS/INC switchable
(only Coolant Proof models).
(except 571.251 - 253). Conforms to factory standard.
Digimatic data output. Delivery in a plastic case.
Reset. Power supply: 1 battery type V357.
Max. measuring speed: Also other models available (e.g. with hook
unlimited. or with tip).
571.252
10
7
ø9
13
20 (27.5) 65 65 65 27.5
ø5 70
571.201 8
5 250
100
571.201 - 571.203 571.204 - 571.207
571.251 - 571.252
Data cables Digimatic, USB Input Tool Direct,
U-WAVE available on request.
Item No. Measuring range/mm Base length/mm Accuracy/mm Price EUR
406.00
571.201 0 - 150 100 ± 0.02 490.00
571.202 0 - 200 100 ± 0.02 500.00
571.203 0 - 300 100 ± 0.03
571.204 0 - 450 250 ± 0.05 1,001.00
571.205 0 - 600 250 ± 0.05 1,063.00
571.206 0 - 750 250 ± 0.06 1,147.00
571.207 0 - 1000 250 ± 0.07 1,264.00
Protection IP67 (Coolant Proof): 460.00
571.251 0 - 150 100 ± 0.02 534.00
571.252 0 - 200 100 ± 0.02 597.00
571.253 0 - 300 100 ± 0.03
0.90
Options: 69.00 C02.229.EN.20240625
836.535 Spare battery type V357 93.00
900.370 Removable bridge, length 180 mm (for depth calipers up to 300 mm) 107.00
900.371 Removable bridge, length 260 mm (for depth calipers up to 300 mm)
900.372 Removable bridge, length 320 mm (for depth calipers up to 300 mm)
© 2024, Schut Geometrische Meettechniek bv 86 Measuring instruments and systems 2023/2024
