Schut Geometrical Metrology DEPTH CALIPERS
HELIOS-PREISSER depth calipers
Depth calipers with or without hook. The models with a hook have graduations on both sides of the
scale, allowing reverse usage (i.e. without hook) of the instrument.
Measuring range: 0 - 1000 mm. Locking screw.
Vernier: 0.05 mm. Matt chrome-plated vernier.
Accuracy: ± 0.03 mm. Length (l) and width (w) of the hook at a scale
cross-section of 8 x 3 mm: 12 x 5 mm,
12 x 4 mm: 16 x 10 mm.
836.402
l Stainless steel, matt chrome-plated beam
w 836.412
Item No. Meas. Base Cross- Price
Stainless steel range length section EUR
Item No. Meas. Base Cross- Price mm mm scale/mm
range length section EUR
mm mm scale/mm Without hook: 8 x 3 93.00
Without hook: 836.402 0 - 200 100 12 x 4 112.00
836.622 0 - 200 100 8 x 3 74.00 836.403 0 - 300 150 12 x 4 172.00
With hook: 836.404 0 - 500 150 20 x 5 262.00
836.628 0 - 500 150 12 x 4 167.00 836.405 0 - 500 250 20 x 5 437.00
836.407 0 - 800 250 20 x 5 618.00
836.410 0 - 1000 250
With hook: 8 x 3 106.00
836.412 0 - 200 100 12 x 4 130.00
836.413 0 - 300 150 12 x 4 208.00
836.414 0 - 500 150
Mitutoyo depth calipers
Depth calipers also available with hook or with fine adjustment.
Measuring range: 0 - 300 mm. Item No. Meas. range Vernier Price
Vernier: 0.05 mm or 0.02 mm. 527.201 mm mm EUR
Locking screw. 527.202
Length measuring base: 100 mm. 527.203 0 - 150 0.05 139.00
Stainless steel construction. 0 - 200 0.05 151.00
0 - 300 0.05 203.00
527.121 0 - 150 0.02 145.00
527.122 0 - 200 0.02 161.00
527.123 0 - 300 0.02 204.00
527.201 Options: 69.00
900.370 Measuring base 180 mm 93.00
900.371 Measuring base 260 mm 107.00 C02.364.EN.20250106
900.372 Measuring base 320 mm
