DEPTH CALIPERS Schut for Precision

TESA TWIN-Cal absolute digital depth calipers IP67

New generation IP67 depth calipers, TESA TWIN-Cal, with an absolute measuring system and a
“soft touch” grip. These depth calipers have a unique connectivity concept TESA LINK. All TWIN-
Cal depth calipers are equipped with a data output. Connect the TESA Link Connector to the TWIN-
Cal for “plug and play” (wireless) data transfer in combination with the free to download TESA
Data-Viewer software. Waterproof, hardened stainless steel depth calipers, in different versions of
the beam’s measuring face. Suited for use with removable bridges. There is also a small depth gauge
available.

 Measuring range: 0 - 500 mm.  Max. measuring speed: approx. 2.5 m/s.
 Resolution: 0.01 mm.  Locking screw.
 mm/inch conversion.  Protection: IP67 (also in combination with
 Digit height: 11 mm.
 Automatic switch-off. data output cable).
 Reset.  ISO 13385-2.
 Standard supplied with data output (USB,
8.5
Digimatic or wireless).
 Delivery in a plastic case with a manufacturer

measuring report.
 Power supply: 1 battery type CR2032.

A 4 15 5 Type III 2 Type IV
4 15.5

24.5
Type II
Type I
10

B

783.357 Item No. Measuring Base length B Price
range/mm A/mm mm EUR

Removable bridges* Short cut measuring face (I): 8 498.00
783.350 0 - 200 100 8 550.00
783.352 0 - 300 150 8 679.00
783.353 0 - 500 150

Item No. Meas. face Height Price Measuring face with one hook (II): 642.00
l x w/mm h/mm EUR 783.354 0 - 300 150 8 755.00
783.355 0 - 500 150 8
782.886 200 x 8 10 ± 0.005 220.00
782.949 300 x 8 16 ± 0.005 237.00 Measuring face with two hooks (III):
782.887 400 x 8 16 ± 0.005 245.00 783.356 0 - 300 150 8 714.00

Measuring face with rotary stop (IV):
783.357 0 - 250 100 8.5
783.358 0 - 350 100 8.5
783.359 0 - 500 150 8.5
lwA w 566.00
ø2 628.00
* Not suited for use with 783.360.B 792.00
h

C02.315.EN.20250106
Small depth gauge with steel depth rod:
783.360 0 - 25 50 7.4 412.00

783.360 Options: 0.50
495.157 Battery type CR2032 128.00
783.301 1 TESA Link Connector USB 262.00
783.302 1 TESA Link Connector Digimatic 52.00
783.555 1 TESA Link Connector Bluetooth

1 The TESA Link Connector will replace the battery cover.
