Schut Geometrical Metrology DEPTH CALIPERS

TESA depth calipers

Hardened stainless steel depth calipers with a matt chrome-plated beam and vernier. Reduced scale
section for easy access to difficult measuring points. The main scale is slightly set back for wear
protection. Suited for use with removable bridges.

 Measuring range: 0 - 500 mm.  ISO 13385-2.
 Vernier: 0.02 or 0.05 mm.  Delivery in a plastic case with a declaration
 Locking screw.
of conformity.

Type I 782.876
783.571
ø

8 Type II

2 Type III

Removable bridges*

Item No. Measuring face Height Price
l x w/mm h/mm EUR
62.00
783.627 180 x 8 17 83.00
783.628 260 x 8 17 94.00
783.629 320 x 8 17
A C
D
hType IV

C02.316.EN.20240625lww

* For depth calipers from 300 mm.

Measuring Base length Dimensions/mm Vernier 0.05 mm Vernier 0.02 mm
range/mm
A/mm C D ø Item No. Price EUR Item No. Price EUR

Short cut measuring face (I):

0 - 150 100 3 8 – 782.872 89.00 782.300 89.00
782.075 99.00 783.571 99.00
0 - 200 100 3 8 – 782.076 110.00 783.572 110.00
782.873 140.00 783.612 140.00
0 - 300 150 4 12 –

0 - 500 150 4 12 –

Steel tip (II): 100 3 8 1.5 782.304 109.00 782.870 109.00
0 - 150 100 3 8 1.5 782.079 123.00 783.573 123.00
0 - 200 100 3 8 1.5 – 782.305 105.00
0 - 250 150 4 12 2 782.161 132.00 783.574 132.00
0 - 300

Measuring face with rotary stop (III):

0 - 150 150 4 12 – 782.858 134.00 782.306 134.00
782.876 167.00 782.307 167.00
0 - 250 150 4 12 – 782.877 212.00 782.308 212.00

0 - 500 150 4 12 –

Convertible models with a hook and a short cut measuring face (IV):

0 - 150 100 3 8 – 782.879 128.00 782.878 128.00
139.00 783.575 139.00
0 - 200 100 3 8 – 782.162 150.00 782.882 150.00
174.00 782.884 174.00
0 - 300 150 4 10 – 782.883

0 - 500 150 4 10 – 782.885
