Schut Geometrical Metrology PROBES AND PROBE SYSTEMS

Probes and accessories (continued)

Cylinder styli with thread M2

Item No. Cylinder Total EWL 1 Weight Price
ø/mm length 1/mm mm g EUR
EWL EWL EWL EWL

876.141 1.5 11 1.5 0.3 19.00 876.141 876.142 876.073 876.143
876.142 3 13 3.8 0.6 19.00 (steel) (steel) (ruby) (ruby)
876.073 1 15 8 0.3 233.00
876.143 1.5 15 8.5 0.3 205.00
876.144 2 20 7.2 0.5 142.00
876.145 4 20 10 0.9 188.00
960.296 2 8 23 5 4.5 76.00
842.301 0.2 26 3 0.35
EWL EWL
EWL
1 Total length: from the base of the stem up to the center of the ball.
EWL: effective working length. 876.144 876.145 960.296 EWL
2 Radius bottom side 40 mm. (ruby) (ruby) (stainless steel) 842.301
(tungsten
carbide)

Parallel hemispherical ended styli (tungsten carbide) 876.146
with thread M2 876.147
876.148
876.149

Item No. Cylinder Total EWL * Weight Price EWL EWL EWL

ø/mm length */mm mm g EUR

876.146 0.3 10.2 2.7 0.3 168.00 EWL
876.147 0.5 15.3 7.8 0.3 166.00
876.148 1 35.5 29.8 0.7 134.00 876.150
876.149 1.5 15.8 8.3 0.6 120.00 876.151
876.150 2 16 8.5 0.8 120.00 876.152
876.151 2 40 32 2 72.40
876.152 3 22.5 22.5 2 120.00

* Total length: from the base of the stem up to the center of the ball. EWL EWL
EWL: effective working length.

EWL

Special purpose styli with thread M2

Item No. Length Weight Material Price
mm g EUR

876.160 15 0.7 stainless steel 24.00 876.160 876.161 876.162
876.161 10 0.7 tungsten carbide 87.00 (pointer, (pointer, (hollow ball,
876.162 11 3.3 ceramic 261.00 stainless steel, tungsten C24.206.EN.20240626
point 30°) carbide, ceramic,
radius 0.1 mm) spherical
ø 18 mm)
