PROBES AND PROBE SYSTEMS Schut for Precision

TP20 probe system The probe module is connected to the probe
body by a highly repeatable magnetic kinematic
The TP20 probe consists of two parts; a probe coupling, which allows the automatic (CNC) or
body, and a detachable probe module that con­ manual exchange of modules without the need
tains the kinematic touch sensor and carries the to requalify the stylus tips.
stylus assembly.
Seven probe module options are available,
The probe body has a standard M8 x 1.25 each with a preset trigger force designed to
screw connector, which enables simple fitment ensure maximum probe performance when
to all CMMs with a Renishaw standard probe using different stylus configurations.
head (including PH6). The body contains a

magnetic prox­
imity switch to
inhibit trigger­ing
of the probe
during auto­
matic module
changing with
the MCR20.
(The TP20 NI,
Non‑Inhibit,
is not affected by magnetic fields and must be
inhibited through software. The TP20 NI is
available on request.)

M8 x 1.25 Module Unidirectional 2D (XY) form Trigger force/N Overal displacement Length
ø 13.2 mm t ype1 repeata bility meas. de viation (nom inal at stylus tip) (max at s tylus tip) L
18.5 mm 5 mm (2σ) /µm PTV at 10 mm/µm XY Z XY 2 +Z/mm –Z/mm
mm
LF 0.35 ± 0.6 0.055 0.65 ± 14° 3.1 - 19.5
19.5
SF 0.35 ± 0.8 0.08 0.75 ± 14° 4.0 - 19.5
19.5
MF 0.5 ± 1.0 0.1 1.9 ± 14° 3.7 - 24.5
69.5
EF 0.65 ± 2.0 0.1 3.2 ± 14° 2.4 - 94.5

L 6-way 0.80 ± 1.5 0.14 1.6 ± 14° 4.5 -

EM1 0.35 ± 0.8 0.08 0.75 ± 14° 4.0 1.5

E M2 0.35 ± 0.8 0.08 0.75 ± 14° 4.0 -

1 Probe length: 10 mm, except MF: 25 mm and EF: 50 mm.
2 The probe module can get detached if this value is exceeded.

Item No. Description Price EUR C24.202.EN.20240626
TP20 probe sets (incl. stylus tools/cleaning kit and manual): 2,725.00
876.198 Probe body, probe module SF 3,025.00
876.244 Probe body, two probe modules SF 3,025.00
876.200 Probe body, probe modules SF and MF 1,145.00
1,040.00
Other set compositions are available on request. 1,040.00
876.180 Probe module LF: with low force (green) 1,070.00
876.170 Probe module SF: with standard force (black) 1,350.00
876.171 Probe module MF: with medium force (gray) 1,255.00
876.172 Probe module EF: with extended force (brown) 1,290.00
876.194 Probe module 6W: 6-way (blue) 18.30
876.190 Extension module EM1 (standard force)
876.195 Extension module EM2 (standard force)
876.168 CK200 cleaning kit
