PROBES AND PROBE SYSTEMS Schut for Precision

Probes and accessories (continued)

Ruby ball styli with ceramic stem and thread Ruby ball styli with carbon fiber stem and
M2, total length 1 50 mm thread M2, total length 1 50 mm

876.127
876.128
876.129
876.130
876.131
876.132

Item No. Ball EWL 1 Weight Price Item No. Ball EWL 1 Weight Price
ø/mm mm g EUR ø/mm mm g EUR

876.127 3 42.5 0.83 70.40 876.130 4 50.5 1 86.00
876.128 4 50 0.91 70.40 876.131 5 50.5 1.1 89.00
876.129 5 50 1.31 70.40 876.132 6 50.5 1.2 92.00

1 Total length: from the base of the stem up to the center of the ball. EWL: effective working length.

Star styli (fixed) with thread M2 Disc styli with thread M2

876.133 876.137 876.138
(steel) (steel)

876.081
(ruby)

876.134 876.136

960.297 960.591 876.139 876.140
(steel) (steel)

Item No. Ball Work 3 Weight Price Item No. Disc Disc thick- Weight Price
ø/mm ø/mm g EUR ø/mm ness/mm g EUR

876.133 1 10 0.5 173.00 876.081 6 2 4 0.6 66.00 C24.205.EN.20240626
876.134 2 20 1.3 130.00 876.137 25 3 3.8 92.00
876.136 2 30 1.8 125.00 876.138 18 2.5 4 3 112.00
960.297 1 11 1.2 357.00 876.139 18 3 4 2.7 102.00
960.591 – 2 11.5 1.3 511.00 876.140 25 2.5 4 4 112.00

2 Cylinder stylus, radius 0.5 mm. 4 Size is incl. ball probe on the disc.
3 Span (center distance).

© 2024, Schut Geometrische Meettechniek bv 532 Measuring instruments and systems 2023/2024
