PROBES AND PROBE SYSTEMS Schut for Precision

Probes and accessories (continued)

Stylus extensions with thread M2 Item No. Length Weight Price
mm g EUR

stainless steel length ø 3 mm Stainless steel: 0.2 11.00
carbon fiber ø 3 mm ø 3.5 mm 876.067 5 0.4 13.00
876.077 10 0.9 14.00
876.070 20 1.4 15.00
876.164 30 1.8 17.00
876.165 40

length Carbon fiber: 0.9 80.00
ø 3 mm 876.153 40 1 83.00
876.154 50 1.3 86.00
876.155 70 1.5 89.00
876.156 90

ceramic Ceramic:
876.157
length 876.158 30 0.97 61.80
876.159 40 1.22 64.40
50 1.51 67.00

Stylus knuckles to put the probe in any desired position

876.072 Item No. Thread EWL * Center Weight Price
876.087 mm offset/mm g EUR

876.072 M2 8 4.5 1.6 55.00
876.087 M2 16.5 – 1.3 58.80

* EWL: effective working length.

Stylus centers for a maximum of 5 styli

Item No. Thread EWL * Center Weight Price
mm size/mm g EUR

876. 071 876. 064 876.071 M2 7.5 7.5 1.1 65.30
4-way: 5-way: 876.064 M2 8 7.5 0.8 41.00
3 side (120°) 4 side (90°)
1 bottom 1 bottom * EWL: effective working length.

Adapters (stainless steel) Item No. Thread Length Weight Price

876.074 external/internal mm g EUR
960.276
876.065 876.074 M2/M3 7 0.4 12.00
960.276 M2.5/M2 5 13.40
876.065 M3/M2 5 0.6
9.00

Styli tool for fitting styli to probe modules, couplings and extentions

876.166 Item No. Description Price EUR

876.166 Styli tool 8.00 C24.207.EN.20240626
for M2 and M3 threaded styli
