Schut Geometrical Metrology PROBES AND PROBE SYSTEMS

PH6 Fixed Probe Head Qualification spheres

The PH6 is a compact, vertical probe head for  Ball: ø 8 or ø 25 mm, made of ceramics.
a single probe, with a fixed cable. The correct  Delivery with a manufacturer measuring
shank with cable combination must be chosen
to suit the mounting features of report.
your CMM. Many combinations
are possible and available on 3.9 50707.008
request. 9.5
 Weight: 48 g (without shank 6
5.4 8
and cable). 11.4
 Probe status identification:
5.9
1 LED. 16.3
 Cable connection: fixed cable
100
(specify on order). 7.5
 Probe mounting: M8 thread. 15.5
ø8 ø8 ø12.5
ø12.5
707.013 65 707.024

Item No. Description Price EUR Item No. Description Price EUR

876.0611 PH6 Fixed Probe Head 323.00 Qualification sphere ø 8 mm: 445.00
707.0251 For DeMeet-220 398.00
707.0262 For DeMeet-4xx/705
390.00
Qualification sphere ø 25 mm: 366.00
707.0131 For DeMeet-220 277.00
707.0242 For DeMeet-4xx/705
1 Equipped with PL1 cable (0.71 m) and MS1/T shank 707.0082 Ball only; M6 external thread
(ø 9.500 - 9.512 mm).
1 Thread M4.
2 Thread M6.

MCR20 Probe Module Changing Rack

The MCR20 is designed to securely hold up to six probe modules for automatic (CNC) changing
and to protect them from airborne contaminants which may be present in the working environment.
 Height:

876.205: 145 mm,
635.141: 108.5 mm,
635.140: 110.5 mm.
 Capacity for 6 TP20 modules.
 Inhibit range: 50 mm.
 Delivery with base, without probe modules.

Item No. Description Price EUR

876.205 876.205 MCR20 2,685.00 C24.303.EN.20240626
© 2024, Schut Geometrische Meettechniek bv 635.141 MCR20 DeMeet-220 2,570.00
635.140 MCR20 DeMeet-4xx/705 2,610.00
