Schut Geometrical Metrology PROBES AND PROBE SYSTEMS

Probes and accessories (continued)

Ruby ball styli with tungsten carbide stem and thread M2

876.079 Item No. Ball EWL * Weight Price
876.075 ø/mm mm g EUR
876.110
Total length * 10 mm:
876.111 876.079 0.3 2 0.3 114.00
876.080 876.075 0.5 3 0.3 103.00
876.112 876.110 0.7 4 0.3 84.00
876.113
Total length * 20 mm: 0.5 51.00
876.111 1 7 0.41 56.00
876.080 1 12.5 1.98 55.00
876.112 1.5 15 1.98 60.10
876.113 5 20

876.101 Total length * 30 mm: 0.4 71.00
876.114 876.101 1 20.5 0.58 60.10
876.115 876.114 1.5 25 0.99 55.00
876.116 876.115 2 25 1.48 55.00
876.117 876.116 2.5 25 1.49 60.10
876.118 876.117 3 25 1.57 60.10
876.119 876.118 4 30 2.57 60.10
876.119 5 30

876.120 Total length * 40 mm: 1.29 60.10
876.121 876.120 2 35 1.95 60.10
876.122 876.121 2.5 35 1.97 64.40
876.123 876.122 3 35 2.04 64.40
876.124 876.123 4 40 3.17 64.40
876.124 5 40

Total length * 50 mm: 2.44 64.40
876.135 3 42.5 2.52 64.40
876.125 4 50 3.75 64.40
876.126 5 50

* Total length: from the base of the stem up to the
center of the ball. EWL: effective working length.

876.135
876.125
876.126
