Schut Geometrical Metrology ALUFIX FIXTURE SYSTEM

Alufix base plates

Alufix base plates serve as a basis for small to medium
fixtures. They can be connected on all six sides using quick
or screw connection elements and can therefore be used in an
extremely flexible way.

The Alufix Grid base plates are provided with threaded
through holes on one side for elements to be screwed into.

Various sizes and base sizes (Alufix 16, 40
and 50) available. These Alufix plates are also
available in a lighter ECO version which have a
favourable price-performance ratio.

Alufix quaders

Solid Alufix quaders serve as connection between a base plate and
workpiece support. They can be connected on all six sides using quick
or screw connection elements.

Quaders are available in single and double models.
Various sizes and base sizes (Alufix 16, 40 and 50) available.

Alufix Light quaders

Alufix Light quaders serve as a frame or connection
between a base plate and the workpiece in medium or large
fixtures. To obtain weight reduction Alufix has designed this
“light” version. The rectangular bars (quaders) are hollow
instead of solid, and are available in single, double and triple
models. They can be connected on all four long sides using
quick or screw connection elements. The end faces can be
connected using special coupling plates.

Various sizes and base sizes (Alufix 16, 40 and 50)
a­ vailable. These Alufix Light quaders are also available in a
lighter ECO version which have a favourable price-perfor-
mance ratio.

C21.203.EN.20250106
