Page 443 - Schut Catalog

Schut Geometrical Metrology GRADUATED RULERS

Stainless steel rulers

 Measuring range: 0 - 2000 mm. Item No. Dimensions Price EUR
 Graduation: 1 mm. l x w x t/mm 13.40
 Matt chrome-plated stainless steel surface. 74.00
 With mm graduation on the upper edge. 99.00
 With 0.5 mm graduation on the lower

edge.

With mm/0.5 mm graduation:
775.584 1000 x 35 x 1.2
775.585 1500 x 40 x 2
775.586 1 2000 x 40 x 2

With mm/mm graduation:
The first 100 mm on the lower edge have a 0.5 mm
graduation.
775.304 1 2000 x 41 x 2 198.00

1 Delivery ex Groningen, Netherlands.

Stainless steel rulers 910.323

 Measuring range: 0 - 1000 mm.
 Graduation: 1 mm on the front side on the

upper and lower edges, 0.5 mm on the back
side on the upper and lower edges.
 Matt chrome-plated stainless steel surface.
 EC class II.
 Etched graduation.

Item No. Dimensions Price
910.323 l x w x t/mm EUR
910.324 300 x 30 x 1 4.40
910.325 500 x 30 x 1 5.40
1000 x 30 x 1 11.80

Self-adhesive rulers

 Measuring range: 0 - 400 mm. Vernier 0.1 mm
 Graduation: 1 mm, vernier: 0.1 mm.  10 scale devisions on 19 mm.
 Blue anodized aluminum.  Non-adhesive, furnished with two fixing
 With self-adhesive back.
 Suitable for positioning on measuring devices holes ø 2.5 mm.

and machine elements.

Item No. Measuring Dimensions Price
range/mm l x w x t/mm EUR
5.80
775.901 0 - 200 208 x 16 x 0.5 10.10 C14.203.EN.20250106
775.902 0 - 300 308 x 16 x 0.5 19.90
775.903 0 - 400 408 x 16 x 0.5 2.40

775.900 Vernier 0.1 mm 40 x 10 x 0.5

© 2025, Schut Geometrische Meettechniek bv 443 Measuring instruments and systems 2023/2024
