GRADUATED RULERS Schut for Precision

Stainless steel rulers with L → R or R → L numbering

 Measuring range: 0 - 12 000 mm. Available on request:
 Graduation: 1 mm (type B: 0.5 mm). – with graduation from top to bottom or from
 Matt chrome-plated stainless steel surface.
 Etched graduation. bottom to top,
 EC class II (up to 4000 mm). – with different combinations (mm/mm,
 Rulers from the main table with hanger hole.
mm/inch, mm/blanc, etc.),
– with 0-point in the middle.
– Thickness: from 300 mm: 1 mm,

from 500 mm: 2 mm.

835.124

835.266

Item No. Price Item No. Price Item No. Price Item No. Price Dimensions

EUR EUR EUR EUR l x w x t/mm

L → R type A: R → L type A: L → R type B: R → L type B: 835.355
835.120 1.60 835.121 1.60 835.421 1.60 835.422 1.60 150 x 13 x 0.5
835.122 1.80 835.123 1.80 835.298 1.80 835.440 1.80 200 x 13 x 0.5
835.124 2.10 835.125 2.10 835.427 2.10 835.441 2.10 250 x 13 x 0.5
835.126 2.30 835.127 2.30 835.129 2.30 835.442 2.30 300 x 13 x 0.5
835.130 4.00 835.131 4.00 835.354 4.00 835.443 4.00 500 x 18 x 0.5
835.132 10.20 835.133 10.20 835.252 10.20 835.444 10.20 1000 x 18 x 0.5
835.134 15.30 835.135 15.30 835.428 15.30 835.445 15.30 1500 x 18 x 0.5
835.136 24.60 835.137 24.60 835.429 24.60 835.446 24.60 2000 x 18 x 0.5
835.138 32.90 835.139 32.90 835.430 32.90 835.447 32.90 2500 x 18 x 0.5
835.140 37.30 835.141 37.30 835.431 37.30 835.448 37.30 3000 x 18 x 0.5
835.142 41.00 835.143 41.00 835.432 41.00 835.449 41.00 3500 x 18 x 0.5
835.144 79.00 835.145 79.00 835.433 79.00 835.450 79.00 4000 x 18 x 0.5
835.146 91.00 835.147 91.00 835.413 91.00 835.451 91.00 5000 x 18 x 0.5
835.148 120.00 835.149 120.00 835.434 120.00 835.452 120.00 6000 x 18 x 0.5
835.150 199.00 835.151 199.00 835.035 199.00 835.453 199.00 7000 x 30 x 1
835.152 230.00 835.153 230.00 835.435 230.00 835.454 230.00 8000 x 30 x 1
835.154 252.00 835.155 252.00 835.436 252.00 835.455 252.00 9000 x 30 x 1
835.156 315.00 835.157 315.00 835.437 315.00 835.456 315.00 10000 x 30 x 1
835.158 340.00 835.159 340.00 835.438 340.00 835.457 340.00 11000 x 30 x 1
835.160 380.00 835.161 380.00 835.439 380.00 835.458 380.00 12000 x 30 x 1

Type A: mm / mm (bottom and top side 1 mm graduation).
Type B: 0.5 mm / 1 mm (top side 0.5 mm, bottom side 1 mm graduation).

Rulers with a self-adhesive back

Item No. Additional costs Price EUR With 0-point in the middle

835.165 For rulers 13.80 Item No. Dimensions Price
up to 1000 mm (price per piece) l x w x t/mm EUR
For rulers 13.80 4.60
from 1000 mm (price per meter) 835.266 200 x 13 x 0.5 C14.305.EN.20240626

The self-adhesive back is not separately available. Other sizes are also available.
