SCALE UNITS Schut for Precision

Digital horizontal scale units

These scale units are available in two different models. Up to 300 mm the model matches the photo
of the 906.403, from 450 mm the photo of the 906.406.

 Measuring range: 0 - 1000 mm. Item No. Measuring Accuracy Price
 Resolution: 0.01 mm. range/mm mm EUR
 Repeatability: 0.01 mm.
 mm/inch conversion. 906.400 0 - 100 ± 0.03 35.70
 ABS/INC switchable (from 450 mm). 906.401 0 - 150 ± 0.03 35.70
 On/off switch. 906.402 0 - 200 ± 0.03 52.00
 Reset. 906.403 0 - 300 ± 0.04 83.00
 Preset (from 450 mm).
 Max. measuring speed: 906.404 0 - 450 ± 0.05 141.00
906.405 0 - 500 ± 0.05 167.00
< 500 mm: 1.5 m/s, 906.406 0 - 600 ± 0.05 231.00
≥ 500 mm: 1 m/s. 906.408 0 - 800 ± 0.06 352.00
 Power supply: 906.409 0 - 1000 ± 0.07 440.00
906.400 - 403: 1 battery type V357,
906.404 - 409: 1 battery type CR2032. Options: 0.90
836.535 Spare battery type V357 0.50
495.157 Spare battery type CR2032

906.403

906.406

Digital vertical scale units

 Measuring range: 0 - 1000 mm.  Reset.
 Resolution: 0.01 mm.  Preset (from 500 mm).
 Repeatability: 0.01 mm.  Max. measuring speed: 1 m/s.
 mm/inch conversion.  Power supply:
 ABS/INC switchable.
 On/off switch. 1 battery type V357
(except 906.416 - 419).
Item No. Measuring Accuracy Price
range/mm mm EUR 906.417

906.415 0 - 100 ± 0.03 64.00
906.416 0 - 150 ± 0.03 64.00
906.417 0 - 200 ± 0.03 82.00
906.418 0 - 300 ± 0.04 114.00
906.419 0 - 450 ± 0.05 152.00
906.420 0 - 500 ± 0.05 193.00
906.421 0 - 600 ± 0.05 251.00
906.423 0 - 800 ± 0.06 329.00
906.424 0 - 1000 ± 0.07 454.00

Options: 0.90 C16.218.EN.20240626
836.535 Spare battery type V357 0.50
495.157 Spare battery type CR2032
