Schut Geometrical Metrology SCALE UNITS
Mitutoyo digital horizontal and vertical scale units
These scale units are ideal for a simple digital read-out of linear movements on e.g. machines and
measuring systems.
Measuring range: 0 - 300 mm. Digimatic data output.
Resolution: 0.01 mm. On/off switch.
ABS/INC switchable. Reset.
Protection: IP66
(only Coolant Proof models).
Conforms to factory standard.
Power supply: 1 battery type V357.
572.560 572.602
Data cables Digimatic,
USB Input Tool Direct, U-WAVE
available on request.
348.043
Item No. Measuring Accuracy Price
range/mm mm EUR
Horizontal: ± 0.03 276.00
572.200 0 - 100 ± 0.03 289.00
572.201 0 - 150 ± 0.03 333.00
572.202 0 - 200 ± 0.04 588.00
572.203 0 - 300
Horizontal, IP66 (Coolant Proof): 319.00
572.600 0 - 100 ± 0.03 341.00
572.601 0 - 150 ± 0.03 404.00
572.602 0 - 200 ± 0.03
Vertical: 0 - 100 ± 0.03 516.00
572.560 0 - 150 ± 0.03 599.00
572.561 0 - 200 ± 0.03 665.00
572.562 0 - 300 ± 0.04 755.00
572.563
Option
Item No. Description Price EUR C16.310.EN.20240626
836.535 Spare battery type V357 0.90
