Schut Geometrical Metrology GAUGES

LMW setting rings

Setting rings, manufactured according DIN 2250 form C, 1 - 315 mm.

 DIN 2250 form C. Also available:
 Material: hardened steel. – Higher accuracy,
 The size is indicated on the setting rings – in tungsten carbide from 3 - 38 mm,
– form B rings for pneumatic measuring tools,
to three decimal places to 100 mm. From – intermediate and larger sizes,
100 mm the nominal size is indicated in mm – with coating,
and separately the deviation in μm. – Go and NoGo limit ring gauges.
 Price on request up to 3 mm.

Size Price Size Price Size Price Size Price Size Price
mm EUR mm EUR mm EUR mm EUR mm EUR

1 56.00 18 59.00 43 88.00 80 175.00 165 502.00
1.2 55.00 19 60.00 44 89.00 82 176.00 170 538.00
1.5 55.00 20 61.00 45 90.00 84 184.00 175 574.00
1.8 53.00 21 63.00 46 92.00 85 197.00 180 610.00
2 53.00 22 63.00 47 94.00 86 201.00 185 647.00
2.2 53.00 23 64.00 48 97.00 88 215.00 190 682.00
2.5 53.00 24 65.00 49 101.00 90 220.00 195 718.00
2.8 53.00 25 66.00 50 102.00 92 228.00 200 754.00
3 53.00 26 67.00 52 105.00 94 241.00 210 792.00
3.5 53.00 27 68.00 54 112.00 95 248.00 220 831.00
4 55.00 28 68.00 55 115.00 96 254.00 230 828.00
4.5 53.00 29 69.00 56 118.00 98 259.00 240 908.00
5 57.00 30 71.00 58 120.00 100 263.00 250 996.00
6 57.00 31 72.00 60 123.00 105 277.00 260 1,087.00
7 58.00 32 72.00 62 128.00 110 289.00 270 1,130.00
8 59.00 33 73.00 64 138.00 115 303.00 280 1,173.00
9 34 74.00 65 134.00 120 315.00 290 1,215.00
10 35 75.00 66 137.00 125 329.00 300 1,258.00
11 36 75.00 68 146.00 130 342.00 310 1,307.00
12 37 76.00 70 149.00 135 355.00 315 1,326.00
13 38 77.00 72 155.00 140 368.00
14 39 79.00 74 162.00 145 381.00 Intermediate
15 40 81.00 75 158.00 150 395.00 sizes over
16 41 83.00 76 170.00 155 430.00
17 42 85.00 78 173.00 160 467.00 3 mm are also
available

Measuring reports C12.205.EN.20250106

For all gauges also measuring reports can be ordered.
 Manufacturer measuring report (German) per gauge. Stating of product specifications, measured

values after pro­duction, used traceable measuring devices, measuring inaccuracy and measuring
date. A favourable choice when your quality system does not require traceable certificates.
 Traceable certificate (Dutch) with mea­suring reports of the ordered gauges. Besides stating of the
measured values the extra assurance of an external inspection.

© 2025, Schut Geometrische Meettechniek bv 391 Measuring instruments and systems 2023/2024
