GAUGES                                                                               Schut for Precision

LMW setting rings

Setting rings, manufactured according DIN 2250 form C.

	 Material: hardened steel.                             Also available:
	 The size is indicated on the setting rings             –	intermediate and larger sizes,
                                                          –	Higher accuracy,
  to three decimal places to 100 mm. From                 –	in tungsten carbide from 3 - 38 mm,
  100 mm the nominal size is indicated in mm              –	form B rings for pneumatic measuring tools,
  and separately the deviation in μm.                     –	with coating,
	 Price on request up to 3 mm.                           –	Go and NoGo limit ring gauges.
	 Optional: Manufacturer measuring report
  (German). Stating of product specifications,
  measured values after pro­duction.
	 Optional: Traceable certificate (English) with
  mea­suring reports of the ordered gauges.
  Extra assurance of an external inspection.

Item No. Size 	      Price  Item No. Size 	       Price  Item No. Size 	      Price  Item No. Size 	    Price
               mm    EUR                   mm     EUR                   mm    EUR                   mm  EUR

832.970 	   1      297.00   832.431 	       23   61.00   832.463 	    55    109.00   832.511 	     115    288.00  C12.320.EN.20250605
832.971 	    1.2   297.00   832.432 	       24   62.00   832.464 	    56    113.00   832.512 	     120    300.00
832.972 	    1.5   297.00   832.433 	       25   63.00   832.466 	    58    115.00   832.513 	     125    313.00
832.973 	    1.8   297.00   832.434 	       26   64.00   832.468 	    60    117.00   832.514 	     130    325.00
832.974 	   2      297.00   832.435 	       27   65.00   832.470 	    62    122.00   832.515 	     135    338.00
832.975 	    2.2   297.00   832.436 	       28   65.00   832.472 	    64    132.00   832.516 	     140    350.00
832.976 	    2.5   297.00   832.437 	       29   66.00   832.473 	    65    134.00   832.517 	     145    363.00
832.977 	    2.8   297.00   832.438 	       30   67.00   832.474 	    66    137.00   832.518 	     150    376.00
832.402 	   3      236.00   832.439 	       31   68.00   832.476 	    68    139.00   832.978 	     155    410.00
832.404 	    3.5    53.00   832.440 	       32   69.00   832.478 	    70    142.00   832.519 	     160    444.00
832.406 	   4       52.00   832.441 	       33   69.00   832.480 	    72    147.00   832.979 	     165    478.00
832.407 	    4.5    52.00   832.442 	       34   70.00   832.482 	    74    154.00   832.520 	     170    513.00
832.408 	   5       51.00   832.443 	       35   71.00   832.483 	    75    158.00   832.521 	     175    546.00
832.410 	   6       51.00   832.444 	       36   72.00   832.484 	    76    162.00   832.522 	     180    581.00
832.412 	   7       51.00   832.445 	       37   73.00   832.486 	    78    165.00   832.980 	     185    616.00
832.414 	   8       51.00   832.446 	       38   74.00   832.488 	    80    167.00   832.523 	     190    650.00
832.416 	   9       51.00   832.447 	       39   75.00   832.490 	    82    176.00   832.524 	     195    684.00
832.418 	  10       51.00   832.448 	       40   77.00   832.492 	    84    184.00   832.525 	     200    718.00
832.419 	  11       51.00   832.449 	       41   79.00   832.493 	    85    188.00   832.981 	     210    755.00
832.420 	  12       52.00   832.450 	       42   81.00   832.494 	    86    201.00   832.982 	     220    791.00
832.421 	  13       53.00   832.451 	       43   84.00   832.496 	    88    204.00   832.983 	     230    828.00
832.422 	  14       54.00   832.452 	       44   85.00   832.498 	    90    209.00   832.984 	     240    865.00
832.423 	  15       54.00   832.453 	       45   86.00   832.500 	    92    217.00   832.527 	     250    996.00
832.424 	  16       55.00   832.454 	       46   88.00   832.502 	    94    230.00   832.985 	     260  1,036.00
832.425 	  17       56.00   832.455 	       47   90.00   832.503 	    95    236.00   832.986 	     270  1,076.00
832.426 	  18       56.00   832.456 	       48   92.00   832.504 	    96    242.00   832.987 	     280  1,117.00
832.427 	  19       58.00   832.457 	       49   97.00   832.506 	    98    254.00   832.988 	     290  1,158.00
832.428 	  20       59.00   832.458 	       50   98.00   832.508 	  100     250.00   832.529 	     300  1,198.00
832.429 	  21       60.00   832.460 	       52  100.00   832.509 	  105     263.00
832.430 	  22       60.00   832.462 	       54  106.00   832.510 	  110     275.00
