www.prenar.ee CENTER INSTRUMENTS

Centering device

Convenient tool to find and set up the position of a workpiece on vertical and horizontal machines.
It can also be used to determine the position of a workpiece when the spindle is rotated by hand or
automatic. Easy read-out from stationary dial indicator. Instrument with compact dimensions.
 Max. range of use: 300 mm.
 Scale read-out per rotation: 0 - 3 mm.
 Graduation: 0.01 mm.
 Centering inside and outside with various

probes.
 3 straight and 3 bended probes included.
 Center feeler included.
 Spindle rotating speed max. 700 rpm.
 Compact dimensions (length basic

instrument: 140 mm).
 For horizontal and vertical use suitable.
 Clamping stem: ø 10 mm.
 Delivery in a plastic carrying case.

Item No. Description Price EUR
907.451 Centering device
Option:
907.445 Probe set (7 pieces)

Edge finders

Edge finders for both stationary and rotating use. As soon as the workpiece is touched by the ball­
probe the all around visible LED will light up due to galvanic contact. The ballprobe is held in place
by a spring. When the pressure on the tip becomes too large the ball wil flip away sideways. The edge
finders are also available with additional sound signal for extra working comfort.

 Concentricity: < 0.01 mm. Item No. Clamping stem Length Price
 Diameter ballprobe: 10 mm. ø/mm mm EUR
 Power supply:
907.454 20 162
907.456/460: 2 batteries type V357, 907.456 20 100
907.454/458: 1 battery type 23A.

907.458

With sound signal:
907.458 20 162
907.460 20 100

907.456 Options: C05.312.Prenar.20240422
836.535 Spare battery type V357

(2 needed)
497.931 Spare battery type 23A

149
