LMW thread plug and ring gauges (continued)

Hardened steel thread plug gauges and thread ring gauges. Manufactured according ANSI B1.2
class 2B (thread plug) and BS 919 2A (thread ring). Manufactured according ANSI B1.2 class 2A
available on request.
For American screw thread UNF

Indication Thread plug Price Thread ring Price Thread ring Price
UNF Go/NoGo DKK Go DKK NoGo DKK

No 0 - 80 823.000 823.001 823.002
No 1 - 72 823.003 823.004 823.005
No 2 - 64 823.006 823.007 823.008
No 3 - 56 823.009 823.010 823.011
No 4 - 48 823.012 823.013 823.014
No 5 - 44 823.015 823.016 823.017
No 6 - 40 823.018 823.019 823.020
No 8 - 36 823.021 823.022 823.023
No 10 - 32 823.024 823.025 823.026
No 12 - 28 823.027 823.028 823.029
1/4 - 28 823.030 823.031 823.032
5/16 - 24 823.033 823.034 823.035
3/8 - 24 823.036 823.037 823.038
7/16 - 20 823.039 823.040 823.041
1/2 - 20 823.042 823.043 823.044
9/16 - 18 823.045 823.046 823.047
5/8 - 18 823.048 823.049 823.050
3/4 - 16 823.051 823.052 823.053
7/8 - 14 823.054 823.055 823.056
1 - 12 823.057 823.058 823.059
11/8 - 12 823.060 823.061 823.062
11/4 - 12 823.063 823.064 823.065

Indication Thread plug Price Thread plug Price Thread ring Price Thread ring Price
UNF Go DKK NoGo DKK Go DKK NoGo DKK
13/8 - 12
11/2 - 12 823.066 823.067 823.068 823.069
823.070 823.071 823.072 823.073

Hardened steel tapered thread plug and thread ring gauges NPT for sealing pipe thread.
Manufactured according ANSI/ASME B1.20.1.
For sealing pipe thread

Indication Thread plug Price Thread ring Price
NPT..." Go/NoGo DKK Go/NoGo DKK

1/16 822.600 822.601
1/8 832.841 832.842
1/4 832.843 832.844
3/8 832.845 832.846
1/2 832.847 832.848
3/4 832.849 832.850
1 832.851 832.852
11/4 822.620 822.621
11/2 822.622 822.623
2 822.624 822.625
21/2 822.626 822.627
3 822.628 822.629
