LMW thread plug and ring gauges (continued)

  Hardened steel thread plug gauges and thread ring gauges. Manufactured according ANSI B1.2
class 2B (thread plug) and BS 919 2A (thread ring). Manufactured according ANSI B1.2 class 2A
available on request.
For American screw thread UNC

Indication 	    Thread plug	  Price	   Thread ring	  Price	   Thread ring	  Price
UNC             Go/NoGo	      DKK      Go	           DKK      NoGo	         DKK

	 No   1	-	64   823.074	               823.075	               823.076	                                    823.120
	 No   2	-	56   823.077	               823.078	               823.079	                                    823.121
	 No   3	-	48   823.080	               823.081	               823.082
	 No   4	-	40   823.083	               823.084	               823.085
	 No   5	-	40   823.086	               823.087	               823.088
	 No   6	-	32   823.089	               823.090	               823.091
	 No   8	-	32   823.092	               823.093	               823.094
	 No 10	-	24    823.095	               823.096	               823.097
	 No 12	-	24    823.098	               823.099	               823.100
	   1/4	 -	20   823.101	               823.102	               823.103
	   5/16	 -	18  823.104	               823.105	               823.106
	   3/8	 -	16   823.107	               823.108	               823.109
	   7/16	 -	14  823.110	               823.111	               823.112
	   1/2	 -	13   823.113	               823.114	               823.115
	   9/16	 -	12  823.116	               823.117	               823.118
	   5/8	 -	11   823.119	               823.120	               823.121
	   3/4	 -	10   823.122	               823.123	               823.124
	   7/8	 -	  9  823.125	               823.126	               823.127
	 1	 -	  8      823.128	               823.129	               823.130
	 11/8	 -	  7   823.131	               823.132	               823.133
	 11/4	 -	  7   823.134	               823.135	               823.136

                              823.145                823.146

Indication 	    Thread plug	  Price	   Thread plug	  Price	   Thread ring	  Price	  Thread ring	  Price
UNC             Go	           DKK      NoGo	         DKK      Go	           DKK     NoGo	         DKK

	 13/8	-	6      823.137	               823.138	               823.139	              823.140
	 11/2	-	6      823.141	               823.142	               823.143	              823.144
	 13/4	-	5      823.145	               823.146	               823.147	              823.148
	 2	 -	41/2     823.149	               823.150	               823.151	              823.152
	 21/4	-	41/2   823.153	               823.154	               823.155	              823.156
	 21/2	-	4      823.157	               823.158	               823.159	              823.160
	 23/4	-	4      823.161	               823.162	               823.163	              823.164
	 3	 -	4        823.165	               823.166	               823.167	              823.168
	 31/4	-	4      823.169	               823.170	               823.171	              823.172
	 31/2	-	4      823.173	               823.174	               823.175	              823.176
	 33/4	-	4      823.177	               823.178	               823.179	              823.180
	 4	 -	4        823.181	               823.182	               823.183	              823.184

                                                     823.128                823.129                                C12.325.MTS.20250410
