LMW thread plug and ring gauges (continued)                                             832.693
                                                                                        832.694
For metric screw thread with pitch 0.5                                                  832.710
                                                                                        801.438
Indication 	  Thread plug	  Price	  Thread ring	  Price	  Thread ring	  Price
M... x 0.5    Go/NoGo	      DKK     Go	           DKK     NoGo	         DKK             822.227

	5            832.687	              832.688	              803.106	      Price
	6            832.689	              832.690	              802.015	      DKK
	8            832.691	              832.692	              803.549
	 10          832.693	              832.694	              822.108	      Price
	 12          832.695	              832.696	              803.107	      DKK
	 14          822.110	              822.111	              801.720
	 16          822.113	              822.114	              809.491
	 18          822.116	              822.117	              801.536
	 20          822.119	              822.120	              804.936

For metric screw thread with pitch 0.75

Indication 	  Thread plug	  Price	  Thread ring	  Price	  Thread ring
M... x 0.75   Go/NoGo	      DKK     Go	           DKK     NoGo

	6            832.700	              832.701	              801.781
	8            832.702	              832.703	              803.621
	 10          832.704	              832.705	              832.718
	 12          832.706	              832.707	              803.512
	 14          832.708	              832.709	              809.464
	 16          832.710	              832.711	              801.438
	 18          832.712	              832.713	              822.136
	 20          832.714	              832.715	              801.811
	 22          822.160	              822.161	              807.967
	 24          822.163	              822.164	              846.144
	 26          822.166	              822.167	              846.145
	 28          822.169	              822.170	              808.724
	 30          822.172	              822.173	              803.354

For metric screw thread with pitch 1

Indication 	  Thread plug	  Price	  Thread ring	  Price	  Thread ring
M... x 1      Go/NoGo	      DKK     Go	           DKK     NoGo

	8            832.721	              832.722	              802.017
	 10          832.723	              832.724	              802.018
	 11          832.725	              832.726	              803.420
	 12          832.727	              832.728	              802.019
	 14          832.729	              832.730	              803.105
	 16          832.731	              832.732	              802.020
	 18          832.733	              832.734	              803.168
	 20          832.735	              832.736	              802.021
	 22          832.737	              832.738	              832.911
	 24          822.210	              822.211	              804.946
	 25          822.214	              822.215	              801.686
	 26          822.218	              822.219	              806.639
	 27          822.222	              822.223	              803.299
	 28          822.226	              822.227	              801.719
	 30          822.230	              822.231	              803.553
