www.mtsranders.dk                                                                        GAUGES / MEASURING WEDGES

  Drill gauges                                                                             Twist drill grinding gauges

  Gauge in the form of a steel plate with bores                                            For checking twist drills at their top and on
of increasing diameters for determining drill                                            the right value of 120° angle of the twist drill
diameters.                                                                               point. The maximum drill diameter is 50 mm.
	 Increment: 0.1 mm.

Item No. Measuring 	 Number 	 Price
               range/mm of bores DKK

910.501 	 0.5	-	10 	 96

  Measuring wedges                                                                                                                           910.372

  Measuring wedges for quick measurements                                                  Universal twist drill grinding gauge, also
and checks of slits, key-ways, distances, etc.                                           called Y‑gauge. Besides the standard angle
	 Measuring range: 0.4 - 26 mm.                                                         of 120°, this gauge also has a 90° angle for
	 Graduation: 0.05, 0.1 or 0.2 mm.                                                      counter­sink drills, and some special angles for
	 Laser engraving.                                                                      center drills.

                                                                          909.537

                                                                           909.535

                                                                          909.536                              856.443

856.331                                                                                  Item No. Description  Price DKK

   Item No. Measuring 	 Graduation 	 Price                                               910.372 Twist drill grinding gauge                           C12.312.MTS.20250410
                 range/mm mm DKK                                                         856.443 Y‑gauge

   909.535 	 0.4	-	 6 	 0.05
   856.331 	 0.5	-	11 	 0.1
   856.332 * 	 0.5	-	11 	 0.1
   909.536 	 1	 -	15 	 0.1
   909.537 	 2	 -	26 	 0.2
*	Plastic material.
