DIGITAL LENGTH MEASURING SYSTEMS                                                                                                                                                                                   Schut for Precision

Magnescale GB‑ER universal scale systems

  The GB‑ER beats all competition. An                                                                                                                                                         Item No. Type                 Measuring 	 Price
excellent resistance against workshop conditions                                                                                                                                                                            range/mm EUR
(oil, chips and shocks), a high resolution
(0.5 µm) and an expansion coefficient the same                                                                                                                                                346.800 GB‑5ER       	           50             543.00
as the machine itself. Reliable for many years                                                                                                                                                346.801 GB‑10ER      	         100              543.00
and almost maintenance free as all magnetic                                                                                                                                                   346.802 GB‑15ER      	         150              543.00
scales of Magnescale.                                                                                                                                                                         346.803 GB‑20ER      	         200              543.00
	 Measuring range: 0 - 2200 mm.                                                                                                                                                              346.804 GB‑25ER      	         250              543.00
	 Highest resolution: 0.5 µm.                                                                                                                                                                346.805 GB‑30ER      	         300              543.00
	 Accuracy at 20°C: ± (2.5 + 2.5L) µm (L in m).                                                                                                                                              346.806 GB‑35ER      	         350              543.00
	 Max. measuring speed: 60 m/min.                                                                                                                                                            346.807 GB‑40ER      	         400              603.00
	 Output: A/B phase and reference point Z 	                                                                                                                                                  346.808 GB‑45ER      	         450              649.00
                                                                                                                                                                                              346.809 GB‑50ER      	         500              700.00
  (TTL line driver RS422).                                                                                                                                                                    346.810 GB‑55ER      	         550              750.00
	 Linear expansion coefficient: (11 ± 1)·10‑6/°C.                                                                                                                                            346.811 GB‑60ER      	         600              798.00
	 Operating temperature: 0 to 40°C.                                                                                                                                                          346.812 GB‑65ER      	         650              848.00
	 Cross-section: 21 x 25 mm.                                                                                                                                                                 346.813 GB‑75ER      	         750              946.00
	 Total length = 	                                                                                                                                                                           346.814 GB‑85ER      	         850            1,057.00
                                                                                                                                                                                              346.815 GB‑95ER      	         950            1,182.00
  L ≤   200 mm: L + 104 mm, 	                                                                                                                                                                 346.816 GB‑105ER     	        1050            1,289.00
  L ≤ 2200 mm: L + 120 mm.                                                                                                                                                                    346.817 GB‑125ER     	        1250            1,491.00
	 Cable length: 3 m.                                                                                                                                                                         346.818 GB‑140ER     	        1400            1,663.00
	 Reference point in the center (standard).                                                                                                                                                  346.819 1 GB‑160ER   	        1600            1,856.00
	 Protection: IP65.                                                                                                                                                                          346.820 1 GB‑185ER   	        1850            2,136.00
	 Power supply: 5± 5% Vdc, 200 mA.                                                                                                                                                           346.821 1 GB‑205ER   	        2050            2,407.00
                                                                                                                                                                                              346.822 1 GB‑220ER   	        2200            2,611.00
                                             Overall length = L + 104 (L ≤ 200) or L + 120 (L ≥ 250)

6.5 Mounting hole pitch = L + 91 (L ≤ 200) or L + 107 (L ≥ 250)                                                                        6.5

 45.5 (L ≤ 200)                                    Measuring length (L)                                           45.5 (L ≤ 200)                                                              324.099 Lubricant 300 ml                      12.40
or 53.5 (L ≥ 250)                                                                                                or 53.5 (L ≥ 250)
                       Mounting hole pitch x 1/2
                                            5 x 7 elongated hole                                                        Alignment
                                            * Center footplate                                                                 mark
                                            (L ≥ 1050)
                                                                                                                           Serial no.
9.5                                                                                          20                                                    21
                                                                                                              5
                                                                                                                                                                                              For mounting kits refer to SJ700A.
                                                                                                                  10.5                                                                        1	Delivery ex Groningen, Netherlands.
                                                                                                                                                               25
                                                                                                                                                                    42
                                                                                                                                                                                        36.5

                                                                                             Reference mark

Measuring length mark                               50                        2 - ø 5, ø 9                                                         12 9                                                      LG20  LH70/71   LY71/72
                                                    60                               Slider center                                                  25

                                                    75                                       2 - ø 4.5 x ø 5.5 elongated hole
                                                    85                                       (Mounting hole)

                                                    36 Slider holder

                                                                                                                                       6                                                      GB-ER                              Adapter    LT30
                                                                                                                                           15                                                 Configuration                        CK-T157
                                                                                                                               (31) (7)        20
                                                                                                                                                                                                                      A/B phase
                                 300 44      ø 5.5                            ø9                                                                                                                                      Reference pulse
                                             Round waterproof connector (male)         ø 18
                                                                                                                                                           D-Sub                              Item No. Type                 Length/m Price EUR
                       Round waterproof connector (female)                                                                                                  9-pin
                                                                                                                                                           (male)
ø 18                                                                                                                                        38
                                                                                                                                                   (17.7)
                                                                                                             36                                                                               Extension cables with stainless steel conduit protection:

                                                                                                  30         30  (86.5)                                                                       346.260 CE10‑01C 	 1                          146.00
                                                                              Cable length                        (91)
                                         44
                                                                                                                                                                                              346.261 CE10‑03C 	 3                          146.00
Dimensions

                                                                                                                                                                                              346.262 CE10‑05C 	 5                          174.00

                                                                                                                                                                                              346.263 CE10‑10C     	 10                     268.00

                                                                                                                                                                                              346.867 Adapter cable CK‑T157                 92.00

                                                                                                                                                                                              For connecting to old display types *:        84.00
                                                                                                                                                                                              346.926 Adapter cable CE30                    84.00
                                                                                                                                                                                              346.448 Adapter SZ51‑AB01

                                                                                                                                                                                              *	LG10, LH51/52, LH61 and LY51/52. 	                       C01.206.EN.20250321
                                                                                                                                                                                               Both adapter cable and adapter are needed.
