Schut Geometrical Metrology CALIPERS

TESA calipers

Swiss high-precision stainless steel caliper with a matt chrome-plated beam and vernier.

 Measuring range: 0 - 300 mm.  Locking screw.
 Vernier: 0.02 mm, 0.05 mm or  ISO 13385-1.
 Delivery in a plastic case with a declaration
0.05 mm / 1/128 inch.
of conformity.

781.680

Item No. Measuring Vernier Jaw length Depth Price
range/mm mm / inch mm rod EUR
40
With mm graduation: 40 flat 40.00
781.680 0 - 150 0.02 40 flat 40.00
783.275 0 - 150 0.05 40
783.276 With mm/inch graduation: 50 flat 40.00
783.489 0 - 150 0.02 / 0.001 64 round 40.00
783.276 0 - 150 0.05 / 1/128 59.00
783.277 0 - 200 0.05 / 1/128 flat 107.00
783.278 0 - 300 0.05 / 1/128 –

TESA calipers with outside angled measuring jaws

Specially designed for measuring bore and internal groove diameters, e.g. on internal safety rings.

 Measuring range: 10 - 160 mm.  Locking screw.
 Vernier: 0.05 mm.  Hardened stainless steel construction.
 Conforms to factory standard.
 Delivery in a plastic case with a declaration

of conformity.
 Larger measuring ranges available on request.

782.225

Item No. Measuring Length/mm Price
range/mm A B C EUR

782.225 10 - 160 0.9 3 25 107.00
782.226 20 - 160 2 5 40 118.00

71 Measuring instruments and systems 2023/2024
